Page #26 background image
26 Part Number: 040006847 12/19
Electrical Service
n
Warning
The ice machine must be grounded in accordance
with national and local electrical codes. Do not use
any extension cords. If the supplied power cord is not
long enough to reach the socket, a designated socket
should be installed close to the ice machine.
VOLTAGE
The maximum allowable voltage variation is ±6% of the
rated voltage at start-up of the ice machine’s compressor.
All ice machines are factory pre-wired with a 2 meter (6 ft)
power cord, and no plug is supplied.
FUSE/CIRCUIT BREAKER
A separate fuse/circuit breaker must be provided for each
ice machine.
TOTAL CIRCUIT AMPACITY
The total circuit ampacity is used to determine the wire
size of the power supply line.
The wire size (or gauge) is also dependent upon location,
materials used, length of run, etc. This must be determined
by a qualified electrician.
Ice
Machine
Voltage/Phase/
Cycle
Maximum Fuse/
Air Switch
Specifications
Total Circuit
Ampacity
UG0020
220/1/50 10 2.3
220/1/60 10 2.3
UG0030
220/1/50 15 2.8
220/1/60 15 2.8
115/1/60 15 5.5
UG0040
220/1/50 15 3.0
220/1/60 15 3.0
UG0050
220/1/50 15 4.0
220/1/60 15 4.0
115/1/60 15 6.8
UG0065
220/1/50 15 4.5
220/1/60 15 4.5
UG0080
220/1/50 15 5.5
220/1/60 15 5.5
