Marantz CD6005 - Page 68

FRONT_PWR
FRONT
_
PWR PCB ASS'
Y
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver gold model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D3101-3112 00D9430182609 DIODE , SWITCHING CVD1SS133MT 10
D3111,3112 00D9430182609 DIODE , SWITCHING K/F/U CVD1SS133MT 2
D3201-3208 00D9430182609 DIODE , SWITCHING CVD1SS133MT 8
D3601 90M-HI200020R INFRARED L.E.D U BVDSIR34ST3F 1
D3602 00D9430182609 DIODE , SWITCHING U CVD1SS133MT 1
D3901,3902 00D9430182609 DIODE , SWITCHING CVD1SS133MT 2
D3904 00D9430182609 DIODE , SWITCHING CVD1SS133MT 1
D3905 90M-HD302350R DIODE , ZENER ,1/2W, 27V CVDZJ27BT 1
D3906 90M-HD302480R DIODE , ZENER ,1/2W, 15V CVDZJ15BT 1
D3911-3913 943203500400M DIODE , RECT CVD1SR35-400ART 3 *
D3916-3918 00D9430182609 DIODE , SWITCHING CVD1SS133MT 3
D3919 943203500400M DIODE , RECT CVD1SR35-400ART 1 *
D3929-3931 943203500400M DIODE , RECT CVD1SR35-400ART 3 *
D3932 943206500020M DIODE HEAT SINK ASS'Y (CMY2A138) K/F/U CVDGBJ1006BIA 1 *
D3932 90M-HE200390R DIODE , BRIDGE N HVDGBJ1006 1
D3933 00D9600095607 DIODE , ZENER ,1/2W, 5.6V K/F/U CVDZJ5.6BT 1
D3933 90M-HD302440R DIODE , ZENER ,1/2W, 4.7V N CVDZJ4.7BT 1
D3934 00D9430182609 DIODE , SWITCHING CVD1SS133MT 1
D3935 90M-HD302450R DIODE , ZENER ,1/2W, 13V CVDZJ13BT 1
D3936-3939 943203500400M DIODE , RECT CVD1SR35-400ART 4 *
D3953-3956 00MHD20055100 DIODE , SCHOTTKY (100V/1A) CVD11EQS10GT 4
D3957 00D9430182609 DIODE , SWITCHING CVD1SS133MT 1
D3958,3959 90M-HD302450R DIODE , ZENER ,1/2W, 13V CVDZJ13BT 2
D3960 00D9430182609 DIODE , SWITCHING CVD1SS133MT 1
D4001 90M-HI101040R L.E.D , RED HVD342VCTB7T089 1
D4101 943176100160M L.E.D , 2COLOR(ORANGE,RED) K/F/U CVDGY5Y5U25Y2W 1 *
D4101 90M-HI101040R L.E.D , RED N HVD342VCTB7T089 1
Q3101 943222500200D F.E.T , 2SK2145 (N-CH, 2-3L1C, LOW NOISE, TOSHIBA) CVT2SK2145 1
Q3102 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSC1845FTA 1
Q3104 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 1
Q3105 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSC1845FTA 1
Q3106 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 1
Q3107,3108 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSC1845FTA 2
Q3109 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 1
Q3110 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSC1845FTA 1
Q3111 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 1
Q3112 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSC1845FTA 1
Q3113 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 1
Q3114,3115 00D9430072502 T.R , CHIP , SOT-23 HVTKTC2875B 2
Q3116 943219500200M T.R , CHIP , SOT-23 HVTKRC104S 1 *
Q3117 00D2690191903 T.R , CHIP , SOT-23 HVTKRA104S 1
Q3118 943219500200M T.R , CHIP , SOT-23 K/F/U HVTKRC104S 1 *
Q3201 943222500200D F.E.T , 2SK2145 (N-CH, 2-3L1C, LOW NOISE, TOSHIBA) CVT2SK2145 1
Q3202 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSC1845FTA 1
Q3204 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 1
Q3205 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSC1845FTA 1
Q3206 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 1
Q3207,3208 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSC1845FTA 2
Q3209 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 1
Q3210 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSC1845FTA 1
Q3211 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 1
Q3212 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSC1845FTA 1
Q3213 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 1
Q3214,3215 00D9430072502 T.R , CHIP , SOT-23 HVTKTC2875B 2
Q3301 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 1
Q3302,3303 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSC1845FTA 2
Q3304 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 1
Q3401 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 1
Q3402,3403 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSC1845FTA 2
Q3404 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 1
Q3601 943215500140D T.R,RT1P144C(10K-47K) K/F/U CVTRT1P144C 1
Q3901 943219006820S T.R CVTKTC1027YT 1
Q3902,3903 90M-HX800090R T.R , CHIP , SOT-23 HVTKRC111S 2
Q3904,3905 00D9430154404 T.R HVTKTC3198YT 2
Q3951 nsp HEAT SINK ASS'Y(CVT2SD2081+CMY1A338) CVT2SD2081BSA 1
Q3951A nsp HEAT SINK 25MM CMY1A338 1
Q3951B nsp SCREW CTB3+8FFB 1
Q3951C 943219500190M T.R, 2SD2081, NPN, TO220F, SANKEN CVT2SD2081 1 *
Q3951D nsp COMPOUND , SILICONE K8AYG6260 0.2
Q3952 nsp HEAT SINK ASS'Y(CVT2SB1259+CMY1A338) CVT2SB1259BSA 1
Q3952A nsp HEAT SINK 25MM CMY1A338 1
Q3952B nsp SCREW CTB3+8FFB 1
Q3952C 943219500170M T.R, 2SB1259, PNP, TO220F, SANKEN CVT2SB1259 1 *
Q3952D nsp COMPOUND , SILICONE K8AYG6260 0.2
Q4001 00D9630121606 T.R , CHIP , SOT-23 HVTKRC107S 1
Q4002 943215500140D T.R,RT1P144C(10K-47K) CVTRT1P144C 1
Q4101 00D2690184907 T.R , CHIP , SOT-23 HVTKRA102S 1
Q4102 00D2690184907 T.R , CHIP , SOT-23 K/F/U HVTKRA102S 1
Q4301 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 1
Q4302,4303 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSC1845FTA 2
Q4304 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 1
Q4305,4306 00D9430072502 T.R , CHIP , SOT-23 HVTKTC2875B 2
Q4401 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 1
Q4402,4403 943213500150S NPN, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSC1845FTA 2
Q4404 943211500150S PNP, TO-92, LOW NOISE, HFE:300-600, FAILCHILD CVTKSA992FTA 1
Q4405,4406 00D9430072502 T.R , CHIP , SOT-23 HVTKTC2875B 2
U3601 262010007707S REMOTE SENSOR , R94EV1A U CRVR94EV1A 1
U3901 23171011750AS NJM2845DL1-33 23171011750AS 1 3
U3902 943219500150M I.C, REGULATOR 5PIN,5V, 1.5A CVIBA00JC5WT 1 *
U3902 nsp HEAT SINK ASS'Y(CVIBA00JC5WT+CMY1A337) CVIBA00JC5WTBR
A
1
U3902A nsp HEAT SINK ASS'Y CMYCD6005 1
U3902B nsp HEAT SINK, TR CMY4A300 1
U3902C nsp SCREW CTB3+8FFB 2
U3902D nsp COMPOUND , SILICONE K8AYG6260 0.4
U3904 23171011750AS NJM2845DL1-33 23171011750AS 1 3
U3905 943219500150M I.C, REGULATOR 5PIN,5V, 1.5A CVIBA00JC5WT 1 *
U3905 nsp HEAT SINK ASS'Y(CVIBA00JC5WT+CMY1A337) CVIBA00JC5WTBR
A
1
U3906 943219500140M I.C, REGULATOR(5.0V/TO-252) CVINJM2845DL1-05 1 *
1
