FRONT_PWR
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
U4001 943262010290S SENSOR , REMOTE/U CRVKSM603TH5B 1
U4003 943172100160S V.F.D (FUTABA, 16ST103GINK) CFL16ST103GINK 1
RESISTOR GROUP
R3101,3102 nsp RES, CARBON(1/5W,1Kohm,J) CRD20TJ102T 2
R3104,3105 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 2
R3107,3108 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 2
R3109,3110 nsp RES, CARBON(1/5W,4.7Kohm,J) CRD20TJ472T 2
R3111 00MGD05121160 RES, CARBON(1/5W,120ohm,J) CRD20TJ121T 1
R3112 00MGD05680160 RES, CARBON(1/5W,68ohm,J) CRD20TJ680T 1
R3113 00MGD05121160 RES, CARBON(1/5W,120ohm,J) CRD20TJ121T 1
R3114 00MGD05561160 RES, CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R3115 00MGD05333160 RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R3116 00MGD05561160 RES, CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R3117 nsp RES, CARBON(1/5W,100ohm,J) CRD20TJ101T 1
R3118 00MGD05333160 RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R3119,3120 nsp RES, CARBON(1/5W,470ohm,J) CRD20TJ471T 2
R3121,3122 00MGD05181160 RES, CARBON(1/5W,180ohm,J) CRD20TJ181T 2
R3123,3124 00MGD05220160 RES, CARBON(1/5W,22ohm,J) CRD20TJ220T 2
R3125 nsp RES, CARBON(1/5W,47Kohm,J) CRD20TJ473T 1
R3126 00MGD05680160 RES, CARBON(1/5W,68ohm,J) CRD20TJ680T 1
R3127 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R3128 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
R3129 00MGD05680160 RES, CARBON(1/5W,68ohm,J) CRD20TJ680T 1
R3130 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R3131 00MGD05680160 RES, CARBON(1/5W,68ohm,J) CRD20TJ680T 1
R3132 nsp RES, CARBON(1/5W,100ohm,J) CRD20TJ101T 1
R3133 nsp RES, CARBON(1/5W,10Kohm,J) K/F/U CRD20TJ103T 1
R3201,3202 nsp RES, CARBON(1/5W,1Kohm,J) CRD20TJ102T 2
R3203 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R3206-3208 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 3
R3209,3210 nsp RES, CARBON(1/5W,4.7Kohm,J) CRD20TJ472T 2
R3211 00MGD05121160 RES, CARBON(1/5W,120ohm,J) CRD20TJ121T 1
R3212 00MGD05680160 RES, CARBON(1/5W,68ohm,J) CRD20TJ680T 1
R3213 00MGD05121160 RES, CARBON(1/5W,120ohm,J) CRD20TJ121T 1
R3214 00MGD05561160 RES, CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R3215 00MGD05333160 RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R3216 00MGD05561160 RES, CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R3217 nsp RES, CARBON(1/5W,100ohm,J) CRD20TJ101T 1
R3218 00MGD05333160 RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R3219,3220 nsp RES, CARBON(1/5W,470ohm,J) CRD20TJ471T 2
R3221,3222 00MGD05181160 RES, CARBON(1/5W,180ohm,J) CRD20TJ181T 2
R3223,3224 00MGD05220160 RES, CARBON(1/5W,22ohm,J) CRD20TJ220T 2
R3225 nsp RES, CARBON(1/5W,47Kohm,J) CRD20TJ473T 1
R3226 00MGD05680160 RES, CARBON(1/5W,68ohm,J) CRD20TJ680T 1
R3227 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R3228 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
R3229 00MGD05680160 RES, CARBON(1/5W,68ohm,J) CRD20TJ680T 1
R3230 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R3231 00MGD05680160 RES, CARBON(1/5W,68ohm,J) CRD20TJ680T 1
R3301 nsp RES, CARBON(1/5W,100ohm,J) CRD20TJ101T 1
R3303 nsp RES, CARBON(1/5W,6.8Kohm,J) CRD20TJ682T 1
R3304,3305 nsp RES, CARBON(1/5W,56ohm,J) CRD20TJ560T 2
R3306 nsp RES, CARBON(1/5W,6.8Kohm,J) CRD20TJ682T 1
R3308,3309 nsp RES, CARBON(1/5W,33ohm,J) CRD20TJ330T 2
R3401 nsp RES, CARBON(1/5W,100ohm,J) CRD20TJ101T 1
R3402 nsp RES, CARBON(1/5W,6.8Kohm,J) CRD20TJ682T 1
R3403,3404 nsp RES, CARBON(1/5W,56ohm,J) CRD20TJ560T 2
R3405 nsp RES, CARBON(1/5W,6.8Kohm,J) CRD20TJ682T 1
R3406 nsp RES, CARBON(1/5W,33ohm,J) CRD20TJ330T 1
R3408 nsp RES, CARBON(1/5W,33ohm,J) CRD20TJ330T 1
R3601,3602 nsp RES, CHIP(1608/5%/100ohm) U CRJ10DJ101T 2
R3901 00MGD05104160 RES, CARBON(1/5W,100Kohm,J) K/F/U CRD20TJ104T 1
R3901 nsp RES, CARBON(1/5W,12Kohm,J) N CRD20TJ123T 1
R3902 nsp RES, CARBON(1/5W,10Kohm,J) K/F/U CRD20TJ103T 1
R3902 nsp RES, CARBON(1/5W,6.8Kohm,J) N CRD20TJ682T 1
R3903 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R3904,3905 nsp RES, M-OXIDE FILM(1W/3.3Kohm) N CRG1SANJ332RT 2
R3908 00MGD05104160 RES, CARBON(1/5W,100Kohm,J) K/F/U CRD20TJ104T 1
R3908 nsp RES, CARBON(1/5W,22Kohm,J) N CRD20TJ223T 1
R3909 nsp RES, CARBON(1/5W,47Kohm,J) CRD20TJ473T 1
R3910 nsp RES, CARBON(1/5W,3.3Kohm,J) CRD20TJ332T 1
R3911 nsp RES, CARBON(1/5W,1Kohm,J) CRD20TJ102T 1
R3912 nsp RES, CARBON(1/4W,1.2Kohm,J) K/F/U CRD25TJ122T 1
R3912 943126500060M RES, FLAME RETARDANT(1/4W 5% 100 OHM) CFPS1/4CMHTA N CRG14SANJ101CL
P
1*
R3913 00MGD05822160 RES, CARBON(1/5W,8.2Kohm,J) CRD20TJ822T 1
R3914 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R3915 nsp RES, CARBON(1/4W,1.2Kohm,J) K/F/U CRD25TJ122T 1
R3915 943126500060M RES, FLAME RETARDANT(1/4W 5% 100 OHM) CFPS1/4CMHTA N CRG14SANJ101CL
P
1*
R3916 00MGD05272160 RES, CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R3917 nsp RES, CHIP(1608/5%/270Kohm) CRJ10DJ274T 1
R3918 nsp RES, CHIP(1608/5%/330Kohm) CRJ10DJ334T 1
R3919 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R3921 nsp RES, CHIP(1608/5%/200Kohm) CRJ10DJ204T 1
R3922 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R3923,3924 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R3931 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R3951,3952 nsp RES, CARBON(1/5W,2.2Kohm,J) CRD20TJ222T 2
R4001 nsp RES, CHIP(3216/5%/1ohm) CRJ14CJ1R0T 1
R4002 nsp RES, CHIP(1608/5%/270ohm) CRJ10DJ271T 1
R4003 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R4004,4005 nsp RES, CARBON(1/5W,10ohm,J) CRD20TJ100T 2
R4006 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R4007 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R4008 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R4009,4010 nsp RES, CHIP(1608/5%/1.8Kohm) CRJ10DJ182T 2
R4011,4012 nsp RES, CHIP(1608/5%/680ohm) CRJ10DJ681T 2
R4013 nsp RES, CHIP(1608/5%/330ohm) CRJ10DJ331T 1
R4014,4015 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 2
R4016 nsp RES, CHIP(1608/5%/330ohm) CRJ10DJ331T 1
R4017-4020 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 4
R4021 nsp RES, CHIP(3216/5%/1ohm) CRJ14CJ1R0T 1
R4101 nsp RES, CHIP(1608/5%/1Kohm) K/F/U CRJ10DJ102T 1
R4101 nsp RES, CHIP(1608/5%/330ohm) N CRJ10DJ331T 1
R4102 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R4103 nsp RES, CHIP(1608/5%/1Kohm) K/F/U CRJ10DJ102T 1
R4103 nsp RES, CHIP(1608/5%/10Kohm) N CRJ10DJ103T 1
