Marantz CD6005 - Page 70

FRONT_PWR
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
R4301 nsp RES, CARBON(1/5W,470ohm,J) CRD20TJ471T 1
R4302 00MGD05104160 RES, CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R4303 nsp RES, CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R4304,4305 nsp RES, CARBON(1/5W,56ohm,J) CRD20TJ560T 2
R4306 nsp RES, CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R4307,4308 00MGD05220160 RES, CARBON(1/5W,22ohm,J) CRD20TJ220T 2
R4309 nsp RES, CARBON(1/5W,47Kohm,J) CRD20TJ473T 1
R4310 nsp RES, CARBON(1/5W,10ohm,J) CRD20TJ100T 1
R4311 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R4312 nsp RES, CARBON(1/5W,10ohm,J) CRD20TJ100T 1
R4313 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R4401 nsp RES, CARBON(1/5W,470ohm,J) CRD20TJ471T 1
R4402 00MGD05104160 RES, CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R4403 nsp RES, CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R4404,4405 nsp RES, CARBON(1/5W,56ohm,J) CRD20TJ560T 2
R4406 nsp RES, CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R4407,4408 00MGD05220160 RES, CARBON(1/5W,22ohm,J) CRD20TJ220T 2
R4409 nsp RES, CARBON(1/5W,47Kohm,J) CRD20TJ473T 1
R4410 nsp RES, CARBON(1/5W,10ohm,J) CRD20TJ100T 1
R4411 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R4412 nsp RES, CARBON(1/5W,10ohm,J) CRD20TJ100T 1
R4413 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R4414 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
CAPACIITORS GROUP
C3101 943133501550M CAP , POLYPROPYLENE(FNS(135)-100VDC-561J) CCMP2A561JS13T 1 *
C3102,3103 943133501560M CAP , POLYPROPYLENE(FNS(135)-100VDC-821J) CCMP2A821JS13T 2 *
C3104,3105 943133501570M CAP , POLYPROPYLENE(FAS(133)-200V-181K) CCMP2B181KS17T 2 *
C3106 943133501580M CAP , POLYPROPYLENE(FAS(133)-200V-221K) CCMP2B221KS17T 1 *
C3108 943133501590M CAP , POLYPROPYLENE (FAS(133)-200VDC 470KTP CCMP2B470KS17T 1 *
C3109 00MOA227025R0 CAP, ELECT(220UF/25V, 10X20, ELNA/ROA) CCEA1EROA221T 1
C3110 00MOA107025Z1 CAP , ELECT (ELNA/R0S, 25V/100UF) HCEA1ER101T 1
C3111 nsp WIRE, COPPER(D0.6) C3A206 0.02
C3120 00D2544569720 CAP, ELECT(25V/1000uF) CCEA1ERA3102E 1
C3201 943133501550M CAP , POLYPROPYLENE(FNS(135)-100VDC-561J) CCMP2A561JS13T 1 *
C3202,3203 943133501560M CAP , POLYPROPYLENE(FNS(135)-100VDC-821J) CCMP2A821JS13T 2 *
C3204,3205 943133501570M CAP , POLYPROPYLENE(FAS(133)-200V-181K) CCMP2B181KS17T 2 *
C3206 943133501580M CAP , POLYPROPYLENE(FAS(133)-200V-221K) CCMP2B221KS17T 1 *
C3208 943133501590M CAP , POLYPROPYLENE (FAS(133)-200VDC 470KTP CCMP2B470KS17T 1 *
C3209 00MOA227025R0 CAP, ELECT(220UF/25V, 10X20, ELNA/ROA) CCEA1EROA221T 1
C3210 00MOA107025Z1 CAP , ELECT (ELNA/R0S, 25V/100UF) HCEA1ER101T 1
C3211 nsp WIRE, COPPER(D0.6) C3A206 0.02
C3301 00D2544693900 CAP , ELECT(22uF/50V, ELNA, RFO ) CCEA1HRFO220T 1
C3302 nsp CAP , POLYPROPYLENE(FAS(133)-200V-101K) CCMP2B101KS17T 1
C3303 943134502680M CAP , ELECT(10uF/63V ) CCEA1JH100T 1 *
C3401 00D2544693900 CAP , ELECT(22uF/50V, ELNA, RFO ) CCEA1HRFO220T 1
C3402 nsp CAP , POLYPROPYLENE(FAS(133)-200V-101K) CCMP2B101KS17T 1
C3403 943134502680M CAP , ELECT(10uF/63V ) CCEA1JH100T 1 *
C3501 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C3502 ,3503 nsp CAP, CHIP(1608, 50V/0.1uF) K/F/U CCUS1H104KC 2
C3507 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C3601 13405012840AS CAP, ELECT(10V/100uF) U CCEA1AH101T 1
C3602 nsp CAP, CHIP(1608, 50V/0.1uF) U CCUS1H104KC 1
C3901 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T 1
C3902 nsp CAP, ELECT(10V/220uF) CCEA1AH221T 1
C3903,3904 nsp CAP, CHIP(1608, 50V/0.022uF) CCUS1H223KC 2
C3905 00MOA47702520 CAP, ELECT(25V/470uF) CCEA1EH471E 1
C3906 00D9430175001 CAP, ELECT(25V/47uF) CCEA1EH470T 1
C3907-3909 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 3
C3910 943134502680M CAP , ELECT(10uF/63V ) CCEA1JH100T 1 *
C3911 nsp CAP, CHIP(1608, 50V/0.022uF) CCUS1H223KC 1
C3912 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C3913 nsp CAP, ELECT(50V/2.2uF) CCEA1HH2R2T 1
C3914 00MOA47702520 CAP, ELECT(25V/470uF) CCEA1EH471E 1
C3915 13405022440AS CAP, ELECT(25V/470uF, ELNA, RA3) CCEA1ERA3471E 1
C3916 nsp CAP, CHIP(1608, 50V/0.022uF) CCUS1H223KC 1
C3917 00MOA47702520 CAP, ELECT(25V/470uF) CCEA1EH471E 1
C3918 13405012940AS CAP, ELECT(16V/100uF) CCEA1CH101T 1
C3919 nsp CAP, CHIP(1608, 50V/0.022uF) CCUS1H223KC 1
C3920 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C3921 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C3924 nsp CAP, CHIP(1608, 50V/0.022uF) CCUS1H223KC 1
C3925 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C3926 nsp CAP , ELECT(63V/220uF) CCEA1JH221E 1
C3929 00D2544576713 CAP, ELECT(35V/1000uF, ELNA, RA3)) CCEA1VRA3102E 1
C3930 943134502740M CAP, ELECT(6800UF/25V, RJ4, ELNA) CCEA1ERJ4682E 1 *
C3931 00D9430024408 CAP , CERAMIC(X1/Y2/SC) KCKDKS472ME 1
C3951,3952 943134502750M CAP , ELECT(NICHICON, 35V/1000UF ) CCEA1VLKG102E 2 *
C3953,3954 00D9430148708 CAP, ELECT(50V/47uF) CCEA1HH470T 2
C3955,3956 00MOA227025R0 CAP, ELECT(220UF/25V, 10X20, ELNA/ROA) CCEA1EROA221T 2
C3958,3959 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 2
C4001,4002 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 2
C4003,4004 nsp CAP, CHIP(1608, 50V/22pF) K/F/U CCUS1H220JA 2
C4005-4009 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 5
C4010 943134010670S CAP, ELECT(16V/47uF)-S CCEA1CKS470T 1
C4011 nsp CAP, CHIP(1608, 50V/100pF) CCUS1H101JA 1
C4012,4013 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 2
C4014 943134010670S CAP, ELECT(16V/47uF)-S CCEA1CKS470T 1
C4015-4017 nsp CAP, CHIP(1608, 50V/100pF) CCUS1H101JA 3
C4019 943134501930D CAP, ELECT(50V/10uF)-S CCEA1HKS100TC 1
C4301 943134502680M CAP , ELECT(10uF/63V ) CCEA1JH100T 1 *
C4302 nsp CAP, PE-FILM(100V/220pF/J) CCME2A221JR11T 1
C4303 00D9430175001 CAP, ELECT(25V/47uF) CCEA1EH470T 1
C4304 00D9430148708 CAP, ELECT(50V/47uF) CCEA1HH470T 1
C4305,4306 nsp CAP, CHIP(1608, 50V/1000pF) CCUS1H102KC 2
C4307,4308 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 2
C4401 943134502680M CAP , ELECT(10uF/63V ) CCEA1JH100T 1 *
C4402 nsp CAP, PE-FILM(100V/220pF/J) CCME2A221JR11T 1
C4403 00D9430175001 CAP, ELECT(25V/47uF) CCEA1EH470T 1
C4404 00D9430148708 CAP, ELECT(50V/47uF) CCEA1HH470T 1
C4405 nsp CAP, CHIP(1608, 50V/1000pF) CCUS1H102KC 1
OTHER PARTS GROUP
B3502 nsp PLATE , EARTH(TRONIC ELECTRONICS) CJT1A026 1
B4301 nsp WIRE ASS'Y CWE8202150RV 1
BK10,11 nsp BRACKET , PCB U CMD1A569-V1 4
BK12,13 nsp BRACKET , PCB CMD1A569-V1 4
BN1101 nsp USB WIRE ASS'Y (5PIN,350MM,61205032500AS) CWZCD6004B1101 1
3
