Marantz CD6005 - Page 71

FRONT_PWR
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
BN2101 nsp WIRE ASS'Y (11PIN,160MM,61205033100AS) CWZCD6004B2101 1
BN2201 nsp WIRE ASS'Y (3PIN,140MM,61205032800AS) U CWZCD6004B2201 1
BN2801 nsp WIRE ASS'Y (13PIN,80MM,61205032400AS) CWZCD6004B2801 1
BN3301 nsp WIRE ASS'Y (7PIN,160MM,61205033200AS) CWZCD6004B3301 1
BN3504 nsp WIRE ASS'Y (5PIN,300MM,61205032600AS) CWZCD6004B3504 1
BN3902 nsp WIRE ASS'Y (2PIN,200MM,61205032200AS) CWZCD6004B3902 1
BN3903 nsp WIRE ASS'Y (10PIN,120MM,61205032300AS) CWZCD6004B3903 1
BN4101 nsp WIRE ASS'Y (5PIN,40MM,61205032700AS) CWZCD6004B4101 1
CN3301 nsp WAFER , STRAIGHT(7PIN) CJP07GA19ZY 1
CN3504 nsp LOCKING TYPE , STRAIGHT WAFER , 2.5MM CJP05GI237ZW 1
CN3901,3902 nsp WAFER, 2P, 3.96mm CJP02KA060ZY 2
CN3903 nsp LOCKING TYPE , STRAIGHT WAFER , 2.5MM 10PIN CJP10GI237ZW 1
CN4101 nsp WAFER , STRAIGHT CJP05GA19ZY 1
! F3903 943652500330M FUSE
(
372 Series/4A/TR5
)
CBA2D4000A3EY
T
1*
! F3951,3952 90M-FS001530
R
FUSE
(
0.8A, 372 SERIES/TR5
)
KBA2D0800A3EY
T
2
FCB300 nsp WAFER, FFC(19P-1mm, STRAIGHT) CJP19GA117ZY 1
J4,5 nsp WIRE, COPPER(D0.6) K/F/U C3A206 2
J27 nsp WIRE, COPPER(D0.6) K/F/U C3A206 1
J79 nsp WIRE, COPPER(D0.6) K/F/U C3A206 1
K3101 943643002370S JACK , 1P BOARD (WHITE, GD PLATE) CJJ4M064Z 1
K3201 943643002380S JACK , 1P BOARD (RED, GD PLATE) CJJ4M065Z 1
K3601 90M-YT004860R JACK, STEREO (BLK MOLD) U CJJ2D008Z 1
K4003 943643100150S JACK , USB STRAIGHT(BLACK) CJJ9X006Z 1
K4301 943643102640M JACK , PHONE(6.3mm,4PIN,Silver) CJJ2E036Z 1 *
L3301-3303 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221S
N
3
L3304 nsp FERRITE CHIP BEAD(2012/2200OHM) CLZBLM21BD222TN 1
L3306,3307 nsp FERRITE CHIP BEAD(2012/2200OHM) CLZBLM21BD222TN 2
L3405 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221S
N
1
L4001-4004 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221S
N
4
L4301 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221S
N
1
L4302-4304 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 3
L4305,4306 nsp FERRITE CHIP BEAD(2012/2200OHM) CLZBLM21BD222TN 2
L4307 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
L4308 nsp FERRITE CHIP BEAD(2012/2200OHM) CLZBLM21BD222TN 1
L4401 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221S
N
1
! S3901 00D9430194900 RELAY,G5PA-1,DC6V,1C1P CSL1E002ZE 1
S4001-4007 00D9430004402 SW , TACT CST1A012ZT 7
S4101 00D9430004402 SW , TACT CST1A012ZT 1
! T3901 943101002880M TRANS , SUB C515 U CLT5I009ZU 1
! T3901 90M-TS003180
R
TRANS , SUB CD6002/N N/K CLT5I009ZE 1
! T3901 90M-TS003170
R
TRANS , SUB CD6002/F F CLT5I009ZJ 1
V4301 943129500940M V092Q20FA103 (METAL)(00D2115646001) CVV2U02A103Z 1 *
Z3501 nsp WIRE ASS'Y (1P, 80MM,BLK,#22) CWE5202080A 1
Z3503,3504 nsp WIRE ASS'Y (1P, 80MM,BLK,#22) CWE5202080A 2
Z3911,3912 nsp WIRE ASS'Y (1P, 80MM,BLK,#22) CWE5202080A 2
★ nsp FL SUPPORT CHG1A584 2
4
