Marantz CD6005 - Page 72

DSP_MCU
DSP
_
MCU PCB ASS'
Y
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver gold model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D100 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 1
D300-305 943209001080S DIODE , CHIP , SWITCHING CVD1SS355T 6
D308 90M-HD201820R DIODE, SCHOTTKEY BARRIER HVDRB160L60TE25 1
IC100 943245006980S EOL item I.C , CD DSP (DSP,LQFP-80P) CVITC94A92FG 1
IC101 943239006900S I.C , 5-CH MOTOR DRIVE(REG,SSOP-28P) CVIIP4001CRLTF_CN 1
IC102 90M-HC700640R I.C , 2CH X 4 MUX CVITC74VCX157FT 1
IC103 943231101240D I.C , REGULATOR(SOT-223) CVIKIA1117BS15 1
IC104 943239101150M I.C , DIT (192K,24BIT,TSSOP-16P) CVIAK4104ET-E2 1 *
IC105 943239101160M I.C , USB HOST CONTROLLER(LQFP-48P) CVIUPD63530AGAGAM-A
X
1*
IC106 943239100710S I.C , CURRENT LIMITE(1.5A,UDFN-6P) CVINCP380HMU15AATBG 1
IC300 943246100770D I.C , EEPROM (16KBIT,SOP-8P,K-Line) CVIK24C16BSIRGA 1
IC301 943234009290S I.C , RESET 2.4V (200ms,C-MOS,SOT23-5P) CVIS80124CLMCJIJT2 1
IC303 23671011050AS I.C , IPOD AUTHENTICATION FROM D&M CVI23671011050AS_DM 1
IC304 90M-HC109330R AUDIO DAC (TSSOP-28 PACKAGE) HVICS4398CZ 1
IC302 943243101100D I.C , U-COM (256KB/32KB, LQFP100P) TOSHIBA CVITMPM330FYFG 1
Q1 943219500180M T.R, 2SD1584, NPN, TO-251, RENESAS CVT2SD1584 1 *
Q100 00D9430058908 T.R , CHIP , SOT-23 HVTKTA1504SYRTK 1
Q101 00D2730464901 T.R , CHIP , SOT-23 HVTKTC3875SYRTK 1
Q300 00D2690184907 T.R , CHIP , SOT-23 HVTKRA102S 1
Q301 90M-HX800090R T.R , CHIP , SOT-23 HVTKRC111S 1
Q302 00D2730464901 T.R , CHIP , SOT-23 HVTKTC3875SYRTK 1
Q304 943215500020S T.R,RT1P141C(10K-10K) N CVTRT1P141C 1
Q310 943215500020S T.R,RT1P141C(10K-10K) N CVTRT1P141C 1
Q311 00D2623077900 I.C, HEX INVERTER HVITC74VHCU04FT 1
RESISTOR GROUP
R1 nsp RES, CHIP(1608/5%/15Kohm) CRJ10DJ153T 1
R2 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R3 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R4 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R5 nsp RES, CHIP(1608/5%/0ohm) N/U CRJ10DJ0R0T 1
R6,7 nsp RES, CHIP(1608/5%/0ohm) K/F/U CRJ10DJ0R0T 2
R8 nsp RES, CHIP(1608/5%/33ohm) N CRJ10DJ330T 1
R9 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R10 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R11-14 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 4
R15,16 nsp RES, CHIP(1608/5%/0ohm) K/F/U CRJ10DJ0R0T 2
R17 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R18 nsp RES, CHIP(1608/5%/1Mohm) N CRJ10DJ105T 1
R19 nsp RES, CHIP(1608/5%/0ohm) K/F/U CRJ10DJ0R0T 1
R20,21 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R22 nsp RES, CHIP(1608/5%/1Mohm) K/F/U CRJ10DJ105T 1
R23 nsp RES, CHIP(1608/5%/0ohm) K/F/U CRJ10DJ0R0T 1
R100 nsp RES, CHIP(1608/5%/91ohm) CRJ10DJ910T 1
R101,102 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R103-105 nsp RES, CHIP(1608/5%/18Kohm) CRJ10DJ183T 3
R106-108 nsp RES, CHIP(1608/5%/39ohm) CRJ10DJ390T 3
R109 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R110 nsp RES, CHIP(1608/5%/39ohm) CRJ10DJ390T 1
R111,112 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R113 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 1
R114 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R115 nsp RES, CHIP(1608/5%/15Kohm) CRJ10DJ153T 1
R116 nsp RES, CHIP(1608/5%/330Kohm) CRJ10DJ334T 1
R118-120 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 3
R121 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R122,123 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R124,125 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 2
R126 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R127 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R128 nsp RES, CHIP(1608/5%/15Kohm) CRJ10DJ153T 1
R130 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R131,132 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R134 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R135,136 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R137-139 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 3
R140 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R141,142 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R147 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R149 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R150-152 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 3
R155 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R157 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R158 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R159 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R160 nsp RES, CHIP(1608/5%/47ohm) CRJ10DJ470T 1
R161 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R162,163 nsp RES, CHIP(1608/5%/47ohm) CRJ10DJ470T 2
R165 nsp RES, CHIP(1608/5%/47ohm) CRJ10DJ470T 1
R166 nsp RES, CHIP(1608/5%/22ohm) CRJ10DJ220T 1
R167-171 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 5
R172 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R173 nsp RES, CHIP(1608/5%/1.8Kohm) CRJ10DJ182T 1
R174 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R180,181 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 2
R182 nsp RES, CHIP(1608/5%/68ohm) CRJ10DJ680T 1
R183 nsp RES, CHIP(1608/5%/10ohm) CRJ10DJ100T 1
R184 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 1
R185 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R186 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R187 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R188 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R189-197 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 9
R198-202 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 5
R203-207 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 5
R208 nsp RES, CHIP(1608/5%/100Kohm) K/F/U CRJ10DJ104T 1
R208 nsp RES, CHIP(1608/5%/0ohm) N CRJ10DJ0R0T 1
R209-211 nsp RES, CHIP(1608/5%/0ohm) N CRJ10DJ0R0T 3
R212,213 nsp RES, CHIP(1608/5%/27ohm) CRJ10DJ270T 2
5
