Marantz CD6005 - Page 73

DSP_MCU
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
R214,215 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R216,217 nsp RES, CHIP(1608/5%/15Kohm) CRJ10DJ153T 2
R218 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R300 nsp RES, CHIP(1608/5%/47ohm) CRJ10DJ470T 1
R301 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R302-308 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 7
R310 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R311 nsp RES, CHIP(1608/5%/47ohm) CRJ10DJ470T 1
R312,313 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 2
R314 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R315 nsp RES, CHIP(1608/5%/18Kohm) CRJ10DJ183T 1
R316 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R317 nsp RES, CHIP(1608/5%/3.3Kohm) CRJ10DJ332T 1
R318 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R319 nsp RES, CHIP(1608/5%/3.3Kohm) CRJ10DJ332T 1
R320,321 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 2
R322 nsp RES, CHIP(1608/5%/1Kohm) N CRJ10DJ102T 1
R323 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R326 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R328 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R330 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R331 nsp RES, CHIP(1608/5%/10Kohm) K/F/U CRJ10DJ103T 1
R331 nsp RES, CHIP(1608/5%/100Kohm) N CRJ10DJ104T 1
R332 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R333 nsp RES, CHIP(1608/5%/1Mohm) CRJ10DJ105T 1
R334 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R336 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R338 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R341 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R344,345 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 2
R346-348 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 3
R350,351 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 2
R352,353 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R356,357 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 2
R359 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R360 nsp RES, CHIP(1608/5%/33ohm) N CRJ10DJ330T 1
R361 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R363-366 nsp RES, CHIP(1608/5%/22ohm) CRJ10DJ220T 4
R367 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R368 nsp RES, CHIP(1608/5%/1Mohm) CRJ10DJ105T 1
R369 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R370 nsp RES, CHIP(1608/5%/22ohm) CRJ10DJ220T 1
R371 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R373 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R381,382 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
CAPACIITORS GROUP
C1-4 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 4
C5 00D9430175001 CAP, ELECT(25V/47uF) CCEA1EH470T 1
C6 nsp CAP, CHIP(1608, 10V/1uF) K/F/U CCUS1A105KC 1
C7 13405012840AS CAP, ELECT(10V/100uF) K/F/U CCEA1AH101T 1
C8 00D9430175001 CAP, ELECT(25V/47uF) CCEA1EH470T 1
C9 13405012840AS CAP, ELECT(10V/100uF) K/F/U CCEA1AH101T 1
C103 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C104 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC 1
C105 nsp CAP, CHIP(1608, 50V/1000pF) CCUS1H102KC 1
C106 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C108 943134010660S CAP, ELECT(6.3V/470uF) CCEA0JH471T 1
C109-112 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 4
C113 13405012840AS CAP, ELECT(10V/100uF) CCEA1AH101T 1
C114 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C115 13405012840AS CAP, ELECT(10V/100uF) CCEA1AH101T 1
C116 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C117 13405012840AS CAP, ELECT(10V/100uF) CCEA1AH101T 1
C118 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C119 13405012840AS CAP, ELECT(10V/100uF) CCEA1AH101T 1
C120 00MOA10800620 CAP, ELECT(6.3V/1000uF) CCEA0JH102T 1
C121,122 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 2
C123 00MOA10800620 CAP, ELECT(6.3V/1000uF) CCEA0JH102T 1
C124 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C125 nsp CAP, CHIP(1608, 50V/0.015uF) CCUS1H153KC 1
C126 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C127 nsp CAP, CHIP(1608, 50V/2200pF) CCUS1H222KC 1
C129 nsp CAP, CHIP(1608, 50V/47pF) CCUS1H470JA 1
C130 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC 1
C131 nsp CAP, CHIP(1608, 50V/4700pF) CCUS1H472KC 1
C132,133 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 2
C134 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC 1
C135 nsp CAP, CHIP(1608, 50V/0.015uF) CCUS1H153KC 1
C136 nsp CAP, CHIP(1608, 50V/0.033uF) CCUS1H333KC 1
C137 nsp CAP, CHIP(1608, 50V/5600pF) CCUS1H562KC 1
C138,139 nsp CAP, CHIP(1608, 50V/470pF) CCUS1H471JA 2
C140 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C143 nsp CAP, CHIP(1608, 50V/0.047uF) CCUS1H473KC 1
C145 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C146 nsp CAP, CHIP(1608, 50V/0.047uF) CCUS1H473KC 1
C149 nsp CAP, CHIP(1608, 50V/1000pF) CCUS1H102KC 1
C150 nsp CAP, CHIP(1608, 50V/22pF) CCUS1H220JA 1
C151 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C152 13405012840AS CAP, ELECT(10V/100uF) CCEA1AH101T 1
C153 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C154 13405012840AS CAP, ELECT(10V/100uF) CCEA1AH101T 1
C155 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C157-159 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 3
C160 13405012840AS CAP, ELECT(10V/100uF) CCEA1AH101T 1
C161,162 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 2
C163 13405012840AS CAP, ELECT(10V/100uF) CCEA1AH101T 1
C164 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C165 nsp CAP, CHIP(1608, 50V/1000pF) CCUS1H102KC 1
C166 00D9430175001 CAP, ELECT(25V/47uF) CCEA1EH470T 1
C167 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C168 13405012840AS CAP, ELECT(10V/100uF) CCEA1AH101T 1
C170,171 13405012840AS CAP, ELECT(10V/100uF) CCEA1AH101T 2
C172 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C174,175 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 2
C176 nsp CAP, CHIP(1608, 50V/1000pF) CCUS1H102KC 1
C178,179 nsp CAP, CHIP(1608, 50V/1000pF) CCUS1H102KC 2
6
