Marantz CD6005 - Page 74

DSP_MCU
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
C182 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC 1
C183 nsp CAP, CHIP(1608, 50V/100pF) CCUS1H101JA 1
C184 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C185 13405012840AS CAP, ELECT(10V/100uF) CCEA1AH101T 1
C186 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C191 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C192 13405012840AS CAP, ELECT(10V/100uF) CCEA1AH101T 1
C195 nsp CAP, CHIP(1608, 10V/1uF) CCUS1A105KC 1
C196 nsp CAP, CHIP(1608, 50V/12pF) CCUS1H120JA 1
C197,198 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 2
C199 00MOA10800620 CAP, ELECT(6.3V/1000uF) CCEA0JH102T 1
C200 nsp CAP, ELECT(10V/47uF) CCEA1AH470T 1
C202,203 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 2
C204,205 00MDD91080300 CAP, CHIP(1608, 50V/8pF) K/F/U CCUS1H080DA 2
C204,205 nsp CAP, CHIP(1608, 50V/20pF) N CCUS1H200JA 2
C210-212 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 3
C215,216 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 2
C300,301 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 2
C303 nsp CAP, CHIP(1608, 50V/470pF) CCUS1H471JA 1
C304,305 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 2
C306 nsp CAP, CHIP(1608, 10V/1uF) CCUS1A105KC 1
C308 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C309 13405012840AS CAP, ELECT(10V/100uF) CCEA1AH101T 1
C310-312 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 3
C313 nsp CAP, CHIP(1608, 50V/15pF) CCUS1H150JA 1
C314 nsp CAP, CHIP(1608, 50V/15pF) K/F/U CCUS1H150JA 1
C314 nsp CAP, CHIP(1608, 50V/12pF) N CCUS1H120JA 1
C316 nsp CAP, CHIP(1608, 50V/100pF) CCUS1H101JA 1
C317-321 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 5
C324 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C325 nsp CAP, CHIP(1608, 50V/0.1uF) N CCUS1H104KC 1
C326 00D9430175001 CAP, ELECT(25V/47uF) CCEA1EH470T 1
C327 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C328 13405012840AS CAP, ELECT(10V/100uF) CCEA1AH101T 1
C329 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C330 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC 1
C331 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C332 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC 1
C333,334 nsp CAP, CHIP(1608, 50V/15pF) CCUS1H150JA 2
C335 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C336,337 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC 2
C339 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC 1
C341 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C342 00MOA107025Z1 CAP , ELECT (ELNA/R0S, 25V/100UF) HCEA1ER101T 1
C343 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C344 00MOA33505020 CAP, ELECT(50V/3.3uF) CCEA1HH3R3T 1
C345,346 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 2
C347 00MOA107025Z1 CAP , ELECT (ELNA/R0S, 25V/100UF) HCEA1ER101T 1
C348 nsp CAP, ELECT(50V/33uF) CCEA1HH330T 1
C349,350 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 2
C351 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC 1
C352 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C353 00MOA107025R1 CAP, ELECT (100uF/25V, ROA, ELNA) CCEA1EROA101T 1
C354 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC 1
C355 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
OTHER PARTS GROUP
B1,2 nsp PLATE , EARTH(TRONIC ELECTRONICS) K/F/U CJT1A026 2
BK201 nsp BRACKET , PCB K/F/U CMD1A569-V1 1
CN1101 nsp WAFER , SMD (2MM PITCH) CJP05GA208ZY 1
CN2101 nsp WAFER , STRAIGHT CJP11GA19ZY 1
CN2201 nsp WAFER , SMD (2MM PITCH)-3P U CJP03GA208ZY 1
CN2801 nsp WAFER, STRAIGHT, 13PIN CJP13GA19ZY 1
CN301 nsp WAFER, FFC(7P-1mm, ANGLE) CJP07GB113ZY 1
CWC100 nsp WAFER , SMD (2MM PITCH) CJP06GA208ZY 1
CWC101 nsp WAFER , SMD (2MM PITCH) CJP05GA208ZY 1
FCC300 nsp WAFER, FFC, SMD(19P-1mm, STRAIGHT) CJP19GA193ZY 1
K100 943623100030D MODULE , OPTICAL(TX 16MHz) CJSJST1124 1
K101 943646000840S JACK, 1P(BK),SEPA-GND,GOLD CJJ4M056W 1
K300 943643102610M JACK RCA, 2P(O/O), VERTICAL, SILVER CJJ4N102Z 1 *
L1 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221SN1 1
L2 nsp FERRITE CHIP BEAD(2012/220R) K/F/U CLZBLM21PG221SN1 1
L100 90M-LU000220R INDUCTOR CHIP 10UH (3225 PKG) HLQ10E100KRZ 1
L101-103 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221SN1 3
L105-107 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221SN1 3
L300-303 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221SN1 4
PFCK10 nsp WAFER, FFC, SMD(16P-1mm, STRAIGHT) K/F/U CJP16GA193ZY 1
RN300 nsp RES, CHIP(1608/5%/10Kohm*4) CRJ104DJ103T 1
S300 90M-SS000710R SWITCH , SLIDE KSS2B016Z 1
X100 943141101040M X-TAL, SMD, 48MHz/FCX-03,8.6PF COX48000I086SR 1 *
X300 943141100750D X-TAL, 10MHz, HC-49/SMD, 12pF K/F/U COX10000E120S 1
X300 943141101020M X-TAL, SMD, 10MHz/FCX-03,10PF N COX10000I100SR 1 *
X301 943141101030M X-TAL, SMD, 16.9344MHz/FCX-03,10PF COX16934I100SR 1 *
Z101 nsp WIRE ASS'Y (1P, 80MM,BLK,#22) K/F/U CWE5202080A 1
