Marantz CD6005 - Page 75

EXPLODED
EXPLODED
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver gold model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
C1 nsp FRONT PCB ASS'Y CUP12552Z-4 1
C2 nsp FRONT PCB ASS'Y CUP12552Z-5 1
C3 nsp EARPHONE PCB ASS'Y CUP12552Z-6 1
C4 nsp TRANS PCB ASS'Y CUP12552Z-1 1
！ C4-T3951 943101102260M POWER TRANS
(
U
)
U CLT5N039ZU 1 *
！ C4-T3951 943101102261M POWER TRANS
(
N
)
N/K CLT5N039ZE 1 *
！ C4-T3951 943101102263M POWER TRANS
(
F
)
F CLT5N039ZJ 1 *
C5 943302100130D CJDKT690 CD MECHA ASSY DCD720 CJDKT690 1
C5-1 900302100200S CD MECHANISM (Traverse) -14
C5-2 30201005100AD LM BELT
For LOADING MECHA
-14
C6 nsp AUDIO OUTPUT PCB ASS'Y CUP12552Z-3 1
C7 nsp CD MAIN PCB ASS'Y CUP12551Z 1
C8 nsp POWER PCB ASS'Y CUP12552Z-2 1
！ C9 00MYJ0400264
0
A
C INLET ASS
Y
CJJ8A006ZW 1
M10 nsp FLASHER U
P1 421410006004M BADGE , MARANTZ CGB1A206 1
P2 943415100410M ORNAMENT, DOOR BLACK BK CGR1A552ZB37 1 *
P2 943415100400M ORNAMENT, DOOR SG CGR1A552RMZD10 1 *
P3 943416101150M WINDOW , FIP CGU1A423A12Y 1 *
P4 nsp PANEL , SUB CD5003/N1B BK CGW1A462B37 1
P4 nsp PANEL , SUB SG CGW1A462RMD10 1
P5 943404100590M PANEL , SIDE L BK CGW1A463RNVB37 1 *
P5 943404100600M PANEL , SIDE L SG CGW1A463ROVD10 1 *
P6 943402007080M PANEL , SIDE R CD5003/N1B BK CGW1A464RNB37 1
P6 943402007090M PANEL , SIDE R CD5003/N1SG SG CGW1A464ROD10 1
P7 nsp SHEET , LED CGX1A411Z 1
P8 481510003006M INDICATOR , POWER CGL1A274 1
P9 411510015017M KNOB , TACT POWER AV8003/U BK CBT1A1072 1
P9 411510021036M KNOB , POWER SG CBT1A1072RMD10 1
P10 943411102840M BUTTON , PLAY BK CBT1A1181 2 *
P10 943411102850M BUTTON , PLAY SG CBT1A1181RMD10 2 *
P11 943411102860M BUTTON , USB BK CBT1A1182 1 *
P11 943411102870M BUTTON , USB SG CBT1A1182RMD10 1 *
P12 943411007050M KNOB , LEVEL BK CBN1A170B37 1
P12 00M24AW154120 KNOB , LEVEL SG CBN1A170RMD10 1
P13 nsp CUSHION , FOOT CHG1A360 4
P14 nsp FOOT , FRONT CKL2A042H46 4
P15 nsp HOLDER , PCB CHE170 4
P16 nsp HOLDER , PCB CHE2A030 3
P17 nsp SHEET , SCREW CGX1A439 1
M1 943402104100M PANEL , AL FRONT BK CKM2A203PC23 1 *
M1 943402104110M PANEL , AL FRONT SG CKM2A203PC62 1 *
M2 nsp PLATE , EARTH USB CMC1A370 1
M3 nsp WASHER CNW2A028 1
M4 nsp BRACKET SA7003 33AK CMD1A757 1
M5 nsp FRAME , FRONT CUF2A004 1
M6 nsp BOTTOM PLATE CUA2A298 1
M7 nsp BOTTOM CHASSIS CUA4A289 1
M8 nsp SUPPORT , MECHA CMD1A842 1
M9 401310003002M CABINET , TOP CD5003/N1B BK CKC2A187K117 1
M9 401310003033M CABINET , TOP CD5003/N1SG SG CKC2A187D11 1
M11 nsp PANEL REAR U CKF4A390H 1
M11 nsp PANEL REAR N CKF3A390N 1
M11 nsp PANEL REAR K CKF3A390K 1
M11 nsp PANEL REAR F CKF3A390J 1
S1 nsp SCREW CTB3+8JFB 34
S2 nsp SCREW , DOT CTBD3+8JFB 27
S3 nsp SCREW BK CTW3+8JFZR 6
S3 nsp SCREW SG CTW3+8JFC 6
S4 nsp SCREW CTB4+6FFZR 4
S5 nsp SCREW CTB3+12JFB 4
S6 nsp SCREW CTB3+18JFB 3
S7 nsp SCREW , ROUND CTBR3+6JR 4
S8 nsp SCREW , DOT CTBD3+6FFB 3
★ ns
p
WIRE ASS'Y
(
5P, 250MM, MECHA
)
CWB2B005250GG 1
★ ns
p
WIRE ASS'Y
(
6P, 220MM, MECHA
)
CWB5A906220GG 1
★ 943606502280M CABLE , CARD CD Mecha
(
16P, 1mm, 140mm, A TYPE
)
CWC4F1A16A140A1 1 *
★ 943606007140M CABLE , CARD
(
19P,1.0MM,250MM,B,8MM
)
CWC4F4A19A250B
0
1
★ 00MYJ0400264
0
RECEPTACLE , AC
(
15A/250V,R-301,B21
)
CJJ8A006ZW 1
★ 90M-FC500130R FERRITE , CORE CLZ9Z071Z 1
★ ns
p
INLET WIRE ASS'Y CWZCD6002BN95Z
A
1
★ 00MYJ0400264
0
RECEPTACLE , AC
(
15A/250V,R-301,B21
)
CJJ8A006ZW 1
★ ns
p
WIRE ASS'Y CWZCD6002BN95 1
★ ns
p
TUBE , UL C4B120062 1
8
