Marantz HD-DAC1 - DIGITAL PCB ASSY Component List (Continued); Digital PCB Resistors and Capacitors (Part 1)

DIGITAL
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
R441 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R442 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R443-445 nsp RES, CHIP(1608/5%/22ohm) CRJ10DJ220T 3
R446-449 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 4
R450-452 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 3
R453 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R454 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R456,457 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R458,459 nsp RES, CHIP(1608/5%/27ohm) CRJ10DJ270T 2
R460,461 nsp RES, CHIP(1608/5%/15Kohm) CRJ10DJ153T 2
R462 nsp RES, CHIP(1608/5%/1Mohm) CRJ10DJ105T 1
R463 nsp RES, CHIP(1608/5%/330ohm) CRJ10DJ331T 1
R466 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R468 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R469 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R470-473 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 4
R474 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R475 nsp RES, CHIP(1608/5%/47ohm) CRJ10DJ470T 1
R480-489 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 10
R491,492 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R501-511 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 11
R512-518 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 7
R519,520 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 2
R521 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R522,523 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
RN31 nsp RES, CHIP(1005/5%/1Kohm*4) CRJ064IJ102T 1
RN32-34 nsp RES, CHIP(1005/5%/100ohm*4) CRJ064IJ101T 3
CAPACIITORS GROUP
C101 nsp CAP, SMD ELECT(16V/100uF) HCEC1CRV2101T 1
C102,103 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 2
C104 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C105 nsp CAP, SMD ELECT(16V/100uF) HCEC1CRV2101T 1
C106 nsp CAP, CHIP(1608, 10V/4.7uF) CCUS1A475KC 1
C107,108 nsp CAP, CHIP(1608, 50V/20pF, C0G)_SAMSUNG CCUS1H200JAS 2
C109 nsp CAP, SMD ELECT(16V/100uF) HCEC1CRV2101T 1
C110 nsp CAP, CHIP(1608, 10V/4.7uF) CCUS1A475KC 1
C111 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C112 nsp CAP, CHIP(1608, 10V/4.7uF) CCUS1A475KC 1
C113 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C114 nsp CAP, CHIP(1608, 50V/47pF, C0G)_SAMSUNG CCUS1H470JAS 1
C115 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C116 nsp CAP, CHIP(1608, 10V/4.7uF) CCUS1A475KC 1
C118 nsp CAP, CHIP(1608, 10V/4.7uF) CCUS1A475KC 1
C119 nsp CAP, SMD ELECT(16V/100uF) HCEC1CRV2101T 1
C120 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C121 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C122 nsp CAP, SMD ELECT(16V/100uF) HCEC1CRV2101T 1
C123,124 nsp CAP, CHIP(1608, 10V/4.7uF) CCUS1A475KC 2
C125,126 nsp CAP, SMD ELECT(16V/100uF) HCEC1CRV2101T 2
C127 nsp CAP, CHIP(1608, 10V/4.7uF) CCUS1A475KC 1
C128,129 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 2
C130 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C131 nsp CAP, CHIP(1608, 10V/4.7uF) CCUS1A475KC 1
C132 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C133 nsp CAP, CHIP(1608, 50V/47pF, C0G)_SAMSUNG CCUS1H470JAS 1
C134 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C135 943134503260S CAP , ELECT (100uF/6.3V, PVO, ELNA) CCEC0JPVO101TS 1 *
C136 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C137 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C138 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C139,140 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 2
C141,142 nsp CAP, SMD ELECT(16V/100uF) HCEC1CRV2101T 2
C143,144 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 2
C145,146 nsp CAP, SMD ELECT(16V/100uF) HCEC1CRV2101T 2
C147 nsp CAP, CHIP(1608, 50V/0.015uF, X7R)_SAMSUNG CCUS1H153KCS 1 *
C148 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CCUS1A105KCS 1
C149-160 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 12
C161 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C162-164 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 3
C173 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C174,175 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 2
C176 nsp CAP, SMD ELECT(16V/10uF) HCEC1CRV2100T 1
C177 943134503260S CAP , ELECT (100uF/6.3V, PVO, ELNA) CCEC0JPVO101TS 1 *
C178,179 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 2
C180,181 nsp CAP, SMD ELECT(16V/1uF) HCEC1CRV21R0T 2 *
C182 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C183 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C184 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C185 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C186 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C187 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C188 943134503260S CAP , ELECT (100uF/6.3V, PVO, ELNA) CCEC0JPVO101TS 1 *
C191,192 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 2
C193,194 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 2
C201-204 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 4
C205 nsp CAP, SMD ELECT(16V/10uF) HCEC1CRV2100T 1
C206 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C207 943134503260S CAP , ELECT (100uF/6.3V, PVO, ELNA) CCEC0JPVO101TS 1 *
C214 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C215 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C216 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C217 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C218 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C219 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C220 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C221 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C222 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C223 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C224 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C225 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C226 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C227 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C228 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C229 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C230 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C231 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
