Marantz HD-DAC1 - DIGITAL PCB ASSY Component List (Continued); Digital PCB Capacitors and Other Parts

DIGITAL
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
C232 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C236,237 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 2
C238 943134503260S CAP , ELECT (100uF/6.3V, PVO, ELNA) CCEC0JPVO101TS 1 *
C239-257 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 19
C258 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C259 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C260 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C261 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C262 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C263 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C267 943134503260S CAP , ELECT (100uF/6.3V, PVO, ELNA) CCEC0JPVO101TS 1 *
C301,302 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 2
C303 nsp CAP, CHIP(1608, 50V/12pF, C0G)_SAMSUNG CCUS1H120JAS 1
C304 nsp CAP, CHIP(1608, 50V/18pF, C0G)_SAMSUNG CCUS1H180JAS 1
C305 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C306 943134503260S CAP , ELECT (100uF/6.3V, PVO, ELNA) CCEC0JPVO101TS 1 *
C307-325 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 19
C326 943134503260S CAP , ELECT (100uF/6.3V, PVO, ELNA) CCEC0JPVO101TS 1 *
C327-332 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 6
C333 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CCUI1E103KCS 1
C334-342 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 9
C343 nsp CAP, CHIP(1608, 16V/0.22uF, X7R)_SAMSUNG CCUS1C224KCS 1
C344-367 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 24
C368 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CCUI1E103KCS 1
C369 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C370 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CCUI1E103KCS 1
C373 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C374 943134503260S CAP , ELECT (100uF/6.3V, PVO, ELNA) CCEC0JPVO101TS 1 *
C375-382 nsp CAP, SMD ELECT(16V/10uF) HCEC1CRV2100T 8
C386 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C388-390 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 3
C391 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS 1
C393 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C401 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C402 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C403 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C404 nsp CAP, SMD ELECT(16V/100uF) HCEC1CRV2101T 1
C405-407 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 3
C408-411 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS 4
C412 943134503260S CAP , ELECT (100uF/6.3V, PVO, ELNA) CCEC0JPVO101TS 1 *
C413,414 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 2
C415 943134503260S CAP , ELECT (100uF/6.3V, PVO, ELNA) CCEC0JPVO101TS 1 *
C417 nsp CAP, CHIP(1608, 50V/0.068uF, X7R)_SAMSUNG CCUS1H683KCS 1
C418 nsp CAP, CHIP(1608, 50V/4700pF, X7R)_SAMSUNG CCUS1H472KCS 1
C419 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C420 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C422 nsp CAP, SMD ELECT(16V/10uF) HCEC1CRV2100T 1
C423 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C424 nsp CAP, SMD ELECT(16V/10uF) HCEC1CRV2100T 1
C425 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C429 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C430 nsp CAP, CHIP(1608, 50V/47pF, C0G)_SAMSUNG CCUS1H470JAS 1
C431 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C432 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C433 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C438 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C439 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C440 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C441-444 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 4
C445 nsp CAP, SMD ELECT(25V/4.7uF) HCEC1ERV24R7T 1 *
C446,447 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 2
C448,449 nsp CAP, CHIP(1608, 50V/8pF, C0G)_SAMSUNG CCUS1H080DAS 2
C450-452 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 3
C455 nsp CAP, CHIP(1608, 50V/470pF, C0G)_SAMSUNG CCUS1H471JAS 1
C456 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C458 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C459,460 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS 2
C461,462 nsp CAP, CHIP(1608, 50V/2200pF, X7R)_SAMSUNG CCUS1H222KCS 2
C463 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C464 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C465 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C466,467 nsp CAP, SMD ELECT(16V/10uF) HCEC1CRV2100T 2
C468 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C469 nsp CAP, SMD ELECT(16V/100uF) HCEC1CRV2101T 1
C470,471 nsp CAP, SMD ELECT(16V/10uF) HCEC1CRV2100T 2
C472 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C473 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C474 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C475 nsp CAP, SMD ELECT(16V/10uF) HCEC1CRV2100T 1
C476 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C477-479 nsp CAP, SMD ELECT(16V/10uF) HCEC1CRV2100T 3
C480 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C481 nsp CAP, SMD ELECT(16V/10uF) HCEC1CRV2100T 1
C482 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C484 nsp CAP, CHIP(1608, 50V/10pF, C0G)_SAMSUNG CCUS1H100JAS 1
C485,486 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS 2
C487 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C488 nsp CAP, SMD ELECT(16V/10uF) HCEC1CRV2100T 1
C489 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C490 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C491 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C492 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C493 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C494 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C495 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C496 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C497,498 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 2
OTHER PARTS GROUP
CN11 nsp WAFER, 2mm, SMD, Vertical, 15p CJP15GA208ZY 1 *
CN12 nsp WAFER , SMD (2MM PITCH)-3P CJP03GA208ZY 1
CN41 nsp WAFER , SMD (2MM PITCH) CJP05GA208ZY 1
BK11 nsp PLATE , EARTH(TRONIC ELECTRONICS) CJT1A026 1
BK21 nsp BRACKET , PCB CMD1A569-V1 1
BK31 nsp BRACKET , PCB CMD1A569-V1 1
BK41 nsp BRACKET , PCB CMD1A569-V1 1
JK31 943643102880S JACK , USB_B TYPE CJJ9L020Z 1
