Marantz HD-DAC1 - AUDIO;POWER PCB ASSY Component List (Continued); Audio;Power PCB Capacitors and Other Parts

AUDIOandPOWER
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
R971,972 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 2
R974 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
CAPACIITORS GROUP
C601 943133501550M CAP , POLYPROPYLENE(FNS(135)-100VDC-561J) CCMP2A561JS13T 1
C602,603 943133501560M CAP , POLYPROPYLENE(FNS(135)-100VDC-821J) CCMP2A821JS13T 2
C604,605 943133501570M CAP , POLYPROPYLENE(FAS(133)-200V-181K) CCMP2B181KS17T 2
C606 943133501580M CAP , POLYPROPYLENE(FAS(133)-200V-221K) CCMP2B221KS17T 1
C607 943133501590M CAP , POLYPROPYLENE (FAS(133)-200VDC 470KTP CCMP2B470KS17T 1
C608 nsp CAP , POLYPROPYLENE(FAS(133)-200V-101K) CCMP2B101KS17T 1
C609,610 00MOA227016Z0 CAP, ELECT(16V/220uF),ELNA/ROS CCEA1CR221T 2
C611 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS 1
C612 00MOA227016Z0 CAP, ELECT(16V/220uF),ELNA/ROS CCEA1CR221T 1
C613 943133502170S CAP , POLYPROPYLNE (WIMA/100pF /100V) CCMP2A101JA02T 1 *
C614,615 00MOA227025R0 CAP, ELECT(220UF/25V, 10X20, ELNA/ROA) CCEA1EROA221T 2
C616 943134502650M CAP, ELECT (47uF/25V, ROA, ELNA) CCEA1EROA470T 1
C620 943133501550M CAP , POLYPROPYLENE(FNS(135)-100VDC-561J) CCMP2A561JS13T 1
C622 943133501590M CAP , POLYPROPYLENE (FAS(133)-200VDC 470KTP CCMP2B470KS17T 1
C623 943133502180S CAP , POLYPROPYLNE (WIMA/1nF /100V) CCMP2A102JA02T 1 *
C624 00MOA107025R1 CAP, ELECT(ROA, 25V/100UF, 10X16) CCEA1EROA101T 1
C625,626 nsp CAP,ELECT(2200uF/25V , RA3 , ELNA) CCEA1ERA3222E 2
C629 nsp CAP , POLYPROPYLENE(SEORYONG, PPF A 103 J 100) CCMP2A103JR16T 1
C632 943134503270S CAP, ELECT(16V/470uF),ELNA/ROS CCEA1CROS471E 1 *
C633 nsp CAP , POLYPROPYLENE(SEORYONG, PPF A 103 J 100) CCMP2A103JR16T 1
C643,644 nsp CAP, CHIP(1608, 50V/47pF, C0G)_SAMSUNG CCUS1H470JAS 2
C651,652 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 2
C653,654 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 2
C655 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS 1
C657 00MOA107025R1 CAP, ELECT(ROA, 25V/100UF, 10X16) CCEA1EROA101T 1
C658-661 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS 4
C662 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C663,664 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 2
C665,666 00MOA107025R1 CAP, ELECT(ROA, 25V/100UF, 10X16) CCEA1EROA101T 2
C668 00MOA106025R1 CAP, ELECT (10uF/25V, ROA, ELNA) CCEA1EROA100T 1
C669 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C670 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS 1
C671 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C672 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C673 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C674 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C675 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C676 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C678 00MOA107025Z1 CAP , ELECT (ELNA/R0S, 25V/100UF) HCEA1ER101T 1
C686 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C687 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C688 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C701 943133501550M CAP , POLYPROPYLENE(FNS(135)-100VDC-561J) CCMP2A561JS13T 1
C702,703 943133501560M CAP , POLYPROPYLENE(FNS(135)-100VDC-821J) CCMP2A821JS13T 2
C704,705 943133501570M CAP , POLYPROPYLENE(FAS(133)-200V-181K) CCMP2B181KS17T 2
C706 943133501580M CAP , POLYPROPYLENE(FAS(133)-200V-221K) CCMP2B221KS17T 1
C707 943133501590M CAP , POLYPROPYLENE (FAS(133)-200VDC 470KTP CCMP2B470KS17T 1
C708 nsp CAP , POLYPROPYLENE(FAS(133)-200V-101K) CCMP2B101KS17T 1
C709,710 00MOA227016Z0 CAP, ELECT(16V/220uF),ELNA/ROS CCEA1CR221T 2
C711 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS 1
C712 00MOA227016Z0 CAP, ELECT(16V/220uF),ELNA/ROS CCEA1CR221T 1
C713 943133502170S CAP , POLYPROPYLNE (WIMA/100pF /100V) CCMP2A101JA02T 1 *
C714,715 00MOA227025R0 CAP, ELECT(220UF/25V, 10X20, ELNA/ROA) CCEA1EROA221T 2
C716 943134502650M CAP, ELECT (47uF/25V, ROA, ELNA) CCEA1EROA470T 1
C720 943133501550M CAP , POLYPROPYLENE(FNS(135)-100VDC-561J) CCMP2A561JS13T 1
C722 943133501590M CAP , POLYPROPYLENE (FAS(133)-200VDC 470KTP CCMP2B470KS17T 1
C723 943133502180S CAP , POLYPROPYLNE (WIMA/1nF /100V) CCMP2A102JA02T 1 *
C724 00MOA107025R1 CAP, ELECT(ROA, 25V/100UF, 10X16) CCEA1EROA101T 1
C729 nsp CAP , POLYPROPYLENE(SEORYONG, PPF A 103 J 100) CCMP2A103JR16T 1
C732 943134503270S CAP, ELECT(16V/470uF),ELNA/ROS CCEA1CROS471E 1 *
C733 nsp CAP , POLYPROPYLENE(SEORYONG, PPF A 103 J 100) CCMP2A103JR16T 1
C751 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C752 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C753 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C754 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C755 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C756 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C770 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS 1
C771 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C772 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C773 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C778 00MOA107025Z1 CAP , ELECT (ELNA/R0S, 25V/100UF) HCEA1ER101T 1
C788 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C789 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C790 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C791 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C792 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C793 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C797 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C798 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C799 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C901 nsp CAP,ELECT(2200uF/25V , RA3 , ELNA) CCEA1ERA3222E 1
C902,903 nsp CAP, CHIP(1608, 50V/0.022uF, X7R)_SAMSUNG CCUS1H223KCS 2
C904 nsp CAP, ELECT(6.3V/1000uF) CCEA0JH102T 1
C905 00MOA33505020 CAP, ELECT(50V/3.3uF) CCEA1HH3R3T 1
C906 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C907 943133502120S CAP, ELECT(16V/6800uF), 105'C CCEA1CH682ES 1
C908-911 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 4
C912 nsp CAP, ELECT(16V/220uF),ELNA/RA3 CCEA1CRA3221T 1
C913,914 943133502120S CAP, ELECT(16V/6800uF), 105'C CCEA1CH682ES 2
C915 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C916 nsp CAP, ELECT(16V/220uF) CCEA1CH221T 1
C917 943134503280S CAP,ELECT(220uF/63V , RA3 , ELNA) CCEA1JRA3221E 1 *
C918 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C919 943134503290S CAP , ELECT(63V/47UF, ELNA, RFO) CCEA1JRFO470T 1 *
C920,921 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 2
C922 nsp CAP, ELECT(16V/220uF) CCEA1CH221T 1
C923,924 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 2
C925 nsp CAP, ELECT(16V/220uF),ELNA/RA3 CCEA1CRA3221T 1
C926,927 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 2
C930 nsp CAP, ELECT(16V/220uF),ELNA/RA3 CCEA1CRA3221T 1
C931 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C932 nsp CAP, ELECT(6.3V/1000uF) CCEA0JH102T 1
