Marantz HD-DAC1 - AUDIO;POWER PCB ASSY Component List (Continued); Audio;Power PCB Capacitors and Other Parts (Part 2)

AUDIOandPOWER
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
C934 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C935 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C936 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C951 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T 1
C952 nsp CAP, ELECT(50V/10uF),ELNA/RA3,5X11 CCEA1HRA38P100
T
1
C953 13405026100AS CAP, ELECT(3300uF/25V, LKG, NICHICON) CCEA1ELKG332E 1
C954 00MOA106025R1 CAP, ELECT (10uF/25V, ROA, ELNA) CCEA1EROA100T 1
C955 00MOA227025R0 CAP, ELECT(220UF/25V, 10X20, ELNA/ROA) CCEA1EROA221T 1
C956 00MOA107025R1 CAP, ELECT(ROA, 25V/100UF, 10X16) CCEA1EROA101T 1
C957 13405026100AS CAP, ELECT(3300uF/25V, LKG, NICHICON) CCEA1ELKG332E 1
C958 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C959 00MOA227025R0 CAP, ELECT(220UF/25V, 10X20, ELNA/ROA) CCEA1EROA221T 1
C960 nsp CAP,ELECT(2200uF/25V , RA3 , ELNA) CCEA1ERA3222E 1
C961 00MOA107025R1 CAP, ELECT(ROA, 25V/100UF, 10X16) CCEA1EROA101T 1
C962,963 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 2
C964 943134502660M CAP, ELECT (22uF/25V, ROS, ELNA) CCEA1EROS220T 1
C965 00MOA107025R1 CAP, ELECT(ROA, 25V/100UF, 10X16) CCEA1EROA101T 1
C966,967 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 2
C968 943134502660M CAP, ELECT (22uF/25V, ROS, ELNA) CCEA1EROS220T 1
C969 00D2544569720 1000uF/25V 10x20mm ELNA RA3 CCEA1ERA3102E 1
C970 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C971 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C972 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C973 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C974 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C975 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C976 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C977 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C978 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C979 00MOA227016Z0 CAP, ELECT(16V/220uF),ELNA/ROS CCEA1CR221T 1
C980 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C981 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C982 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C983 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C984 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C985 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
OTHER PARTS GROUP
CN61 nsp WAFER , 2P(2.5MM BOARD TYPE) CJP02GB03ZY 1
CN62 nsp LOCKING TYPE , STRAIGHT WAFER , 2mm CJP05GI236ZW 1
CN63 nsp LOCKING TYPE , STRAIGHT WAFER , 2MM CJP13GI236ZW 1
CN64 nsp LOCKING TYPE , STRAIGHT WAFER , 2MM CJP03GI236ZW 1
CN71 nsp WAFER , 2P(2.5MM BOARD TYPE) CJP02GB03ZY 1
CN91 nsp WAFER, 2P, 3.96mm CJP02KA060ZY 1
CN92 nsp WAFER, 2P, 7.92mm CJP02GA89ZY 1
CN93 nsp LOCKING TYPE , STRAIGHT WAFER, 2.5MM CJP07GI237ZW 1
CN94 nsp PIN HEADER (11P,1.25mm,STRAIGHT,B-TO-B) CJP11GI281Z 1
CN98 nsp LOCKING TYPE , STRAIGHT WAFER , 2mm CJP05GI236ZW 1
! CY91-93 963132011940S CAP, CERAMIC
(
X1/Y2,0.01uF,AC250V
)
CCKDKY103MFM 3
BK91,92 nsp PLATE , EARTH(TRONIC ELECTRONICS) CJT1A026 2
BK93-95 nsp BRACKET , PCB CMD1A569-V1 3
BK96,97 nsp BRACKET , PCB M3 CMD1A834 2
BN62 nsp WIRE ASS'Y(5P,2.0MM,80MM) CWB1C00508047 1 *
BN63 nsp WIRE ASS'Y(13P,2.0MM,80MM)SHIELD CWB1C0130804700
1
1*
BN64 nsp WIRE ASS'Y(3P,2.0MM,120MM)SHIELD CWB1C0031204700
1
1*
BN81 nsp WIRE ASS'Y(9P,2.0MM,120MM)SHIELD CWB1C0091204700
2
1*
BN84 nsp WIRE ASS'Y(5P,2.0MM,200MM) CWB1C00520047 1 *
BN92 nsp WIRE ASS'Y(15P,2.0MM,100MM) CWB1C015100AA7 1 *
F901-904 nsp HOLDER , FUSE KJCFC5S 4
! F901 90M-FS001370
R
FUSE
(
218Series, 250V/630mA
)
N,K KBA2C0630TLE
Y
13
! F901 0520100140070 FUSE
(
218Series, 250V/2A
)
U,F KBA2C2000TLE
Y
13
! F902 0520100140070 FUSE
(
218Series, 250V/2A
)
KBA2C2000TLE
Y
13
! F903 0520100150000 FUSE
(
218Series, 250V/3.15A
)
KBA2C3150TLE
Y
13
! F904 943652500620S FUSE
(
S506 Series, 250V/200mA
)
CBA2C0200TLE
C
13
F951,952 943652500510D FUSE(932Series, 250V/1.25A) CBA2J1250TLEBT 2
! F953 90M-FS001530
R
FUSE
(
0.8A, 372 SERIES/TR5
)
KBA2D0800A3EY
T
1
J601,602 nsp WIRE, COPPER(D0.6) C3A206 2
JK61,62 943643101920S JACK , RCA (1P, BK, GOLD PLATE) CJJ4M073ZY 2
JK71,72 943643101920S JACK , RCA (1P, BK, GOLD PLATE) CJJ4M073ZY 2
JW91 nsp WIRE ASS'Y(1P, 80MM,BLK,#22) CWE5202080A 1
JW93 nsp WIRE ASS'Y(1P,150MM,BLACK,UL1007#24,CKM-T) CWE4202150AT 1 *
L602,603 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221S
N
2
L607,608 nsp FERRITE CHIP BEAD(2012/120R) CLZBLM21AG121S
N
2
L611,612 nsp FERRITE CHIP BEAD(2012/120R) CLZBLM21AG121S
N
2
L711,712 nsp FERRITE CHIP BEAD(2012/120R) CLZBLM21AG121S
N
2
L901 nsp BEAD, EMI SUPPRESSION FILTER (1uF/500Mohm) CLZNFM21PC105B1 1
L902 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221S
N
1
L903 nsp BEAD, EMI SUPPRESSION FILTER (1uF/500Mohm) CLZNFM21PC105B1 1
L905 nsp BEAD, EMI SUPPRESSION FILTER (1uF/500Mohm) CLZNFM21PC105B1 1
L910-912 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221S
N
3
L916-921 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221S
N
6
LF91 943149003340S LINE FILTER(10MH) CLZ9Z086Z 1
RL62 943682000810S RELAY,BC3-12H,DC12V,2C2P CSL4A016ZU 1
! RY91 963682010370S RELAY,HL31-1AT-5H,DC5V,1C1
P
CSL1C006ZE 1
! T901 90M-TS003180
R
TRANS , SUB N CLT5I009ZE 1
! T901 943101007210M TRANS , SUB K CLT5I009ZH 1
! T901 943101002880M TRANS , SUB U CLT5I009ZU 1
! T901 90M-TS003170
R
TRANS , SUB F CLT5I009ZJ 1
VR61 943161000920S RES,SEMI FIXED(1K, Vertical) CVN12E102B03T 1
VR71 943161000920S RES,SEMI FIXED(1K, Vertical) CVN12E102B03T 1
WF61 nsp WAFER, FFC(23P-1.25mm, STRAIGHT) CJP23GA115ZY 1
WF94 nsp PIN SOCKET (11P,1.25mm,ANGLE,B-TO-B) CJP11HJ282Z 1
X601 14181008150AS OSC, SMD(24.576MHz, NZ2520S) COX24576I150SN 1
X602 14181008250AS OSC, SMD(22.5792MHz, NZ2520SD) COX22579I150SN 1
★ ns
p
SUPPORT , HEAT SIN
K
CMH1A119 4 *
POWER HEAT SI
N
nsp POWER HEAT SINK ASS`Y CMYHDDAC1/N 1 *
POWER HEAT SI
N
nsp SUPPORT , HEAT SINK CMH1A119 4 *
POWER HEAT SI
N
nsp HEAT SINK CMY1A417 1 *
POWER HEAT SI
N
nsp SCREW CTB3+16JR 4 *
★ ns
p
HEAT SIN
K
CMY1A41
7
1*
★ ns
p
SCREW CTB3+16J
R
4*
★ ns
p
SCREW CTB3+8J
R
6
D912,913-ASSY nsp HEAT SINK ASS'Y(CVDD5SB60+CMY9A138) CVDD5SB60BZA 2 *
D912,913-ASSY nsp HiFi SYSTEM HDDAC1/K1B CMY9A138 2 *
D912,913-ASSY nsp SCREW CTB3+8JR 2
IC92-ASSY nsp IC HEAT SINK ASS'Y (CMY2A395) CVIBA00JC5WTCC
A
1*
IC92-ASSY nsp HiFi SYSTEM HDDAC1/K1B CMY2A395 1 *
