(2) Removethescrews.
(3) Disconnecttheconnectorwires.
Direction of
photograph: D
Direction of
photograph: C
CP401 CP402
CP403
N2706
CP405
PCB 7CH AMP
STYLE PIN:Loose
RADIATOR ASSY
Pleasereferto"EXPLODEDVIEW"forthedisassemblymethodofeachP.W.BincludedinRADIATORASSY.
