5. PCB SPK/PCB SMPS
(1) RemovetheSheet,thenremovethescrewsandSUPPORTERP.C.
(2) Disconnecttheconnectorwire,thenremovethescrews.
CABINET TOP
HDMI UNIT ASSY
→
PCB SPK/PCB SMPS
→
Proceeding :
View from bottom
SUPPORTER P.C.
Sheet
Direction of
photograph: D
CX102
