(3) Disconnecttheconnectorwire,thenremovethescrews.RemovethePCBSPK/PCBSMPSfromthemainunit.
(4) Disconnecttheconnectorboard.
CP1
CP405CP403
CP402
PCB SMPSPCB SPK
Board to board
