SURROUND MODE
This unit is equipped with many surround modes. These are provided to reproduce a variety of surround sound effects, according to the content of the source to be played.
The available surround modes may be restricted depending on the input signal and speaker setup.
THE RELATION BETWEEN THE SELECTED SURROUND MODE AND THE INPUT SIGNAL
The surround mode is selected with the surround mode selector on this unit or the remote controller. However, the sound you hear is subject to the relationship between the selected surround mode and input signal.
That relationship is as follows;
Surround
mode
Input Signal Decoding
Output Channel Front information display
L/R C
SL/
SR
SW Signal format indicators Channel status
AUTO
Dolby Surr. EX Dolby Digital 5.1
‡‡‡‡
2
D EX L, R, C, SL, SR, SW
Dolby D (5.1ch) Dolby Digital 5.1
‡‡‡‡
2
D L, R, C, SL, SR, SW
Dolby D (2ch) Dolby Digital 2.0
‡
–––
2
D L, R
Dolby D (2ch Surr.) Pro Logic
II
Movie
‡‡‡‡
2
D L, R, C, SL, SR, SW
Dolby D (1ch) Dolby Digital 1.0 –
‡
––
2
DC
DTS-ES DTS 5.1
‡‡‡‡
dts ES L, R, C, SL, SR, SW
DTS 96/24 DTS 5.1
‡‡‡‡
dts L, R, C, SL, SR, SW
DTS (5.1ch) DTS 5.1
‡‡‡‡
dts L, R, C, SL, SR, SW
DTS (2ch) DTS 2.0
‡
– – – dts L, R
DTS (1ch) DTS 1.0 –
‡
– – dts C
PCM (Audio) PCM (Stereo)
‡
– – – PCM L, R
PCM 96KHz PCM (96KHz Stereo)
‡
– – – PCM L, R
HDCD PCM (Stereo)
‡
– – – PCM L, R
Analog Stereo
‡
– – – PCM L, R
S.DIRECT
Dolby Surr. EX Dolby Digital 5.1
‡‡‡‡
2
D EX L, R, C, SL, SR, SW
Dolby D (5.1ch) Dolby Digital 5.1
‡‡‡‡
2
D L, R, C, SL, SR, SW
Dolby D (2ch) Dolby Digital 2.0
‡
–––
2
D L, R
Dolby D (2ch Surr.) Pro Logic II Movie
‡‡‡‡
2
D
L, R, C, SL, SR, SW
Dolby D (1ch) Dolby Digital 2.0 –
‡
––
2
DC
DTS-ES DTS 5.1
‡‡‡‡
dts ES L, R, C, SL, SR, SW
DTS 96/24 DTS 5.1
‡‡‡‡
dts L, R, C, SL, SR, SW
DTS (5.1ch) DTS 5.1
‡‡‡‡
dts L, R, C, SL, SR, SW
DTS (2ch) DTS 2.0
‡
– – – dts L, R
DTS (1ch) DTS 1.0 –
‡
– – dts C
PCM (Audio) PCM (Stereo)
‡
– – – PCM L, R
PCM 96KHz PCM (96KHz Stereo)
‡
– – – PCM L, R
HDCD PCM (Stereo)
‡
– – – PCM L, R
Analog Stereo
‡
– – – PCM L, R
DOLBY
(PL
II
movie)
(PL
II
music)
(Pro-Logic)
Dolby Surr. EX Dolby Digital 5.1
‡‡‡‡
2
D EX L, R, C, SL, SR, SW
Dolby D (5.1ch) Dolby Digital 5.1
‡‡‡‡
2
D L, R, C, SL, SR, SW
Dolby D (2ch) Pro Logic
II
‡‡‡‡
2
D L, R, C, SL, SR, SW
Dolby D (2ch Surr.) Pro Logic
II
‡‡‡‡
2
D L, R, C, SL, SR, SW
Dolby D (1ch) Pro Logic
II
–
‡
––
2
DC
DTS-ES – – – – –
DTS 96/24 – – – – –
DTS (5.1ch) – – – – –
DTS (2ch) – – – – –
DTS (1ch) – – – – –
PCM (Audio) Pro Logic
II
‡‡‡‡
PCM L, R, C, SL, SR, SW
PCM 96KHz Pro Logic
II
‡‡‡‡
PCM L, R, C, SL, SR, SW
HDCD Pro Logic
II
‡‡‡‡
PCM L, R, C, SL, SR, SW
Analog Pro Logic
II
‡‡‡‡
PCM L, R, C, SL, SR, SW
Surround
mode
Input Signal Decoding
Output Channel Front information display
L/R C
SL/
SR
SW Signal format indicators Channel status
DTS
Dolby Surr. EX – ––––
Dolby D (5.1ch) – ––––
Dolby D (2ch) – ––––
Dolby D (2ch Surr.) – ––––
Dolby D (1ch) – ––––
DTS-ES DTS 5.1
‡‡‡‡
dts ES L, R, C, SL, SR, SW
DTS 96/24 DTS 5.1
‡‡‡‡
dts L, R, C, SL, SR, SW
DTS (5.1ch) DTS 5.1
‡‡‡‡
dts L, R, C, SL, SR, SW
DTS (2ch) DTS 2.0
‡
– – – dts L, R
DTS (1ch) DTS 1.0 –
‡
– – dts C
PCM (Audio) – ––––
PCM 96KHz – ––––
HDCD – ––––
Analog – ––––
VIRTUAL
(Ref2)
(Wide2)
Dolby Surr. EX Virtual
‡
–––
2
D EX L, R
Dolby D (5.1ch) Virtual
‡
–––
2
D L, R
Dolby D (2ch) Virtual
‡
–––
2
D L, R
Dolby D (2ch Surr.) Virtual
‡
–––
2
D
L, R
Dolby D (1ch) Virtual
‡
–––
2
D L, R
DTS-ES Virtual
‡
– – – dts ES L, R
DTS 96/24 Virtual
‡
– – – dts L, R
DTS (5.1ch) Virtual
‡
– – – dts L, R
DTS (2ch) Virtual
‡
– – – dts L, R
DTS (1ch) Virtual
‡
– – – dts L, R
PCM (Audio) Virtual
‡
– – – PCM L, R
PCM 96KHz Virtual
‡
– – – PCM L, R
HDCD Virtual
‡
– – – PCM L, R
Analog Virtual
‡
– – – PCM L, R
DSP SUR-
ROUND
(HALL)
(ROCK)
(JAZZ)
Dolby Surr. EX – ––––
Dolby D (5.1ch) – ––––
Dolby D (2ch) – ––––
Dolby D (2ch Surr.) – ––––
Dolby D (1ch) – ––––
DTS-ES – ––––
DTS 96/24 – ––––
DTS (5.1ch) – ––––
DTS (2ch) – ––––
DTS (1ch) – ––––
PCM (Audio) –
‡‡‡‡
PCM L, R, C, SL, SR, SW
PCM 96KHz –
‡‡‡‡
PCM L, R, C, SL, SR, SW
HDCD –
‡‡‡‡
PCM L, R, C, SL, SR, SW
Analog –
‡‡‡‡
PCM L, R, C, SL, SR, SW
