NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI)
PART NAME DESCRIPTION
POS.NO.
H/P JK81 90M-YT003160R 90M-YT003160R TERMINAL CJJ2E020Z
H/P R846 nsp nsp RESISTOR 4.7K OHM 1/5W J CRD20TJ472T
H/P R847 nsp nsp RESISTOR 330 OHM 1W J CRG1ANJ331H
H/P R848 nsp nsp RESISTOR 330 OHM 1W J CRG1ANJ331H
H/P R849 nsp nsp RESISTOR 910 OHM 1/5W J CRD20TJ911T
PUSH S/W PCB
PUSH S/W C877 /A1B nsp 90M-DK100800R CERAMIC CAP. DKS471ME KCKDKS471ME
PUSH S/W C877 /A1S nsp 90M-DK100800R CERAMIC CAP. DKS471ME KCKDKS471ME
PUSH S/W C877 /F1N nsp 90M-DK100800R CERAMIC CAP. DKS471ME KCKDKS471ME
PUSH S/W C877 /K1G nsp 90M-DK100800R CERAMIC CAP. DKS471ME KCKDKS471ME
PUSH S/W C877 /N1B 90M-DK100800R 90M-DK100800R CERAMIC CAP. DKS471ME KCKDKS471ME
PUSH S/W C877 /N1G 90M-DK100800R 90M-DK100800R CERAMIC CAP. DKS471ME KCKDKS471ME
PUSH S/W C877 /N1S 90M-DK100800R 90M-DK100800R CERAMIC CAP. DKS471ME KCKDKS471ME
PUSH S/W CN88 /A1B nsp 90M-YP100250R JACK MOLEX35328-02 KJP02GA89ZM
PUSH S/W CN88 /A1S nsp 90M-YP100250R JACK MOLEX35328-02 KJP02GA89ZM
PUSH S/W CN88 /F1N nsp 90M-YP100250R JACK MOLEX35328-02 KJP02GA89ZM
PUSH S/W CN88 /K1G nsp 90M-YP100250R JACK MOLEX35328-02 KJP02GA89ZM
PUSH S/W CN88 /N1B 90M-YP100250R 90M-YP100250R JACK MOLEX35328-02 KJP02GA89ZM
PUSH S/W CN88 /N1G 90M-YP100250R 90M-YP100250R JACK MOLEX35328-02 KJP02GA89ZM
PUSH S/W CN88 /N1S 90M-YP100250R 90M-YP100250R JACK MOLEX35328-02 KJP02GA89ZM
PUSH S/W SW97 /A1B nsp 90M-SP000850R SWITCH JPP1197CSA64 KSH1A001ZV
PUSH S/W SW97 /A1S nsp 90M-SP000850R SWITCH JPP1197CSA64 KSH1A001ZV
PUSH S/W SW97 /N1B 90M-SP000850R 90M-SP000850R SWITCH JPP1197CSA64 KSH1A001ZV
PUSH S/W SW97 /N1G 90M-SP000850R 90M-SP000850R SWITCH JPP1197CSA64 KSH1A001ZV
PUSH S/W SW97 /N1S 90M-SP000850R 90M-SP000850R SWITCH JPP1197CSA64 KSH1A001ZV
POWER TRANSF. PCB.1 (CUP11693-5)
TRNSF. 1 BN96 nsp nsp CONNECTIVE CORD CWB1C908150BM
TRNSF. 1 C107 nsp nsp CERAMIC CAP. 0.01UF 50V ZF CCKT1H103ZF
TRNSF. 1 C108 nsp nsp CERAMIC CAP. 0.01UF 50V ZF CCKT1H103ZF
TRNSF. 1 C109 nsp nsp CERAMIC CAP. 0.01UF 50V ZF CCKT1H103ZF
TRNSF. 1 C110 nsp nsp CERAMIC CAP. 0.01UF 50V ZF CCKT1H103ZF
TRNSF. 1 C111 nsp nsp CERAMIC CAP. 0.01UF 50V ZF CCKT1H103ZF
TRNSF. 1 C112 nsp nsp CERAMIC CAP. 0.01UF 50V ZF CCKT1H103ZF
TRNSF. 1 C117 nsp 00MOA47601640 ELECT CAP. 47UF 16V ZF CCEA1CH470T
TRNSF. 1 C118 nsp nsp CERAMIC CAP. 0.01UF 50V ZF CCKT1H103ZF
TRNSF. 1 C119 nsp 00MOA47605020 ELECT CAP. 47UF 50V ZF CCEA1HH470T
TRNSF. 1 C120 nsp 00MOA47605020 ELECT CAP. 47UF 50V ZF CCEA1HH470T
TRNSF. 1 C121 nsp nsp CERAMIC CAP. 0.01UF 50V ZF CCKT1H103ZF
TRNSF. 1 C122 nsp 00MOA10705020 ELECT CAP. 100UF 50V ZF CCEA1HH101T
TRNSF. 1 C123 nsp 00MOA47701620 ELECT CAP. 470UF 16V ZF CCEA1CH471T
TRNSF. 1 CN14 nsp nsp JACK 7P STRAIGHT CJP07GA19ZY
TRNSF. 1 CN99 nsp nsp JACK 3P STRAIGHT CJP03GA01ZY
TRNSF. 1 D102 90M-HD302190R 90M-HD302190R ZENER DIODE 30V HVDMTZJ30BT
TRNSF. 1 D104 nsp 90M-HD201730R DIODE 1N4003 KVD1N4003ST
TRNSF. 1 D105 nsp 90M-HD201730R DIODE 1N4003 KVD1N4003ST
TRNSF. 1 D108 nsp 90M-HD201730R DIODE 1N4003 KVD1N4003ST
TRNSF. 1 D111 90M-HD302150R 90M-HD302150R ZENER DIODE 6.8V HVDMTZJ6.8BT
TRNSF. 1 J631 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
TRNSF. 1 J632 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
TRNSF. 1 Q131 00MHT600141B0 00MHT600141B0 TRANSISTOR KTA1271Y HVTKTA1271YT
TRNSF. 1 R101 nsp nsp RESISTOR 3.3 OHM KRD25FJ3R3T
TRNSF. 1 R104 90M-NH000080R 90M-NH000080R FUSE RESISTOR 0.47 OHM 1W J KRQ1AJR47H
TRNSF. 1 R105 90M-NH000080R 90M-NH000080R FUSE RESISTOR 0.47 OHM 1W J KRQ1AJR47H
TRNSF. 1 R106 90M-NH000080R 90M-NH000080R FUSE RESISTOR 0.47 OHM 1W J KRQ1AJR47H
TRNSF. 1 R107 90M-NH000080R 90M-NH000080R FUSE RESISTOR 0.47 OHM 1W J KRQ1AJR47H
TRNSF. 1 R108 nsp nsp RESISTOR 4.7 OHM 1/5W J CRD20TJ4R7T
TRNSF. 1 R109 nsp nsp RESISTOR 10 OHM 1/5W J CRD20TJ100T
TRNSF. 1 R110 nsp nsp RESISTOR 4.7 OHM 1/5W J CRD20TJ4R7T
TRNSF. 1 R112 nsp nsp RESISTOR 1.2K OHM 1/5W J CRD20TJ122T
TRNSF. 1 R113 nsp nsp RESISTOR 47K OHM 1/5W J CRD20TJ473T
POWER TRANSF. PCB.2 (CUP11693-7)
TRNSF. 2 C921 nsp nsp FILM CAP 0.1UF 50V J HCQI1H104JZT
TRNSF. 2 C922 nsp nsp FILM CAP 0.1UF 50V J HCQI1H104JZT
