65
NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI)
PART NAME DESCRIPTION
POS.NO.
TRNSF. 2 C925 nsp nsp FILM CAP 0.01UF 50V J HCQI1H103JZT
TRNSF. 2 C926 nsp nsp FILM CAP 0.01UF 50V J HCQI1H103JZT
TRNSF. 2 C931 nsp nsp FILM CAP 0.047UF 50V J HCQI1H473JZT
TRNSF. 2 C932 nsp nsp FILM CAP 0.047UF 50V J HCQI1H473JZT
TRNSF. 2 CN20 nsp nsp JACK MOLEX35313-0310 KJP03GA90ZM
TRNSF. 2 CN93 nsp nsp JACK 2P STRAIGHT CJP02GA01ZY
TRNSF. 2 D990 nsp 90M-HD201730R DIODE 1N4003 KVD1N4003ST
TRNSF. 2 J877 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
TRNSF. 2 J878 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
TRNSF. 2 R997 nsp nsp RESISTOR 4.7 OHM 1/5W J CRD20TJ4R7T
TRNSF. 2 R998 nsp nsp RESISTOR 4.7 OHM 1/5W J CRD20TJ4R7T
TRNSF. 2 RL11 00MLY20240520 00MLY20240520 RELAY PCLH-203D1SP HSL4B018ZU
POWER TRANSF. PCB.3 (CUP11693-8)
TRNSF. 3 BN21 nsp nsp CONNECTIVE CORD CWB1E908070MM
TRNSF. 3 D991 90M-HE200250R 90M-HE200250R DIODE GBJ1504 HVDGBJ1504
TRNSF. 3 J875 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
TRNSF. 3 J876 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
TACT PCB (CUP11693-9)
TACT SW96 /L1G nsp 90M-SP001210R SWITCH 00802-0005 CST1A012ZT
TACT SW96 /U1B nsp 90M-SP001210R SWITCH 00802-0005 CST1A012ZT
TACT SW96 /U1S nsp 90M-SP001210R SWITCH 00802-0005 CST1A012ZT
VIDEO PCB (CUP11693-3)
VIDEO C501 nsp nsp CERAMIC CAP. 47PF 50V JC CCCT1H470JC
VIDEO C502 nsp nsp CERAMIC CAP. 47PF 50V JC CCCT1H470JC
VIDEO C503 nsp nsp CERAMIC CAP. 47PF 50V JC CCCT1H470JC
VIDEO C504 nsp nsp CERAMIC CAP. 47PF 50V JC CCCT1H470JC
VIDEO C505 nsp nsp CERAMIC CAP. 47PF 50V JC CCCT1H470JC
VIDEO C506 nsp nsp CERAMIC CAP. 47PF 50V J HCBS1H470JT
VIDEO C507 nsp nsp CERAMIC CAP. 47PF 50V J HCBS1H470JT
VIDEO C508 nsp nsp CERAMIC CAP. 47PF 50V J HCBS1H470JT
VIDEO C509 nsp nsp CERAMIC CAP. 47PF 50V J HCBS1H470JT
VIDEO C510 nsp nsp CERAMIC CAP. 47PF 50V J HCBS1H470JT
VIDEO C511 nsp nsp CERAMIC CAP. 47PF 50V J HCBS1H470JT
VIDEO C512 nsp nsp CERAMIC CAP. 47PF 50V JC CCCT1H470JC
VIDEO C513 nsp nsp CERAMIC CAP. 68PF 50V J HCBS1H680JT
VIDEO C514 nsp nsp CERAMIC CAP. 68PF 50V J HCBS1H680JT
VIDEO C515 nsp 00MOA10605020 ELECT CAP. 10UF 50V ZF CCEA1HH100T
VIDEO C516 nsp 00MOA10605020 ELECT CAP. 10UF 50V ZF CCEA1HH100T
VIDEO C517 nsp 00MOA10605020 ELECT CAP. 10UF 50V ZF CCEA1HH100T
VIDEO C518 nsp 00MOA10605020 ELECT CAP. 10UF 50V ZF CCEA1HH100T
VIDEO C519 nsp 00MOA10605020 ELECT CAP. 10UF 50V ZF CCEA1HH100T
VIDEO C520 nsp 00MOA10605020 ELECT CAP. 10UF 50V ZF CCEA1HH100T
VIDEO C522 nsp 00MOA10605020 ELECT CAP. 10UF 50V ZF CCEA1HH100T
VIDEO C523 nsp 00MOA10605020 ELECT CAP. 10UF 50V ZF CCEA1HH100T
VIDEO C524 nsp 00MOA10605020 ELECT CAP. 10UF 50V ZF CCEA1HH100T
VIDEO C525 nsp 00MOA47700620 ELECT CAP. 470UF 6.3V ZF CCEA0JH471T
VIDEO C526 nsp nsp CERAMIC CAP. 47PF 50V J HCBS1H470JT
VIDEO C527 nsp 00MOA47700620 ELECT CAP. 470UF 6.3V ZF CCEA0JH471T
VIDEO C528 nsp nsp CERAMIC CAP. 47PF 50V J HCBS1H470JT
VIDEO C529 nsp nsp CERAMIC CAP. 47PF 50V J HCBS1H470JT
VIDEO C530 nsp nsp CERAMIC CAP. 0.022UF 50V Z HCBS1H223ZFT
VIDEO C531 nsp nsp CERAMIC CAP. 0.022UF 50V Z HCBS1H223ZFT
VIDEO C532 nsp nsp CERAMIC CAP. 0.022UF 50V Z HCBS1H223ZFT
VIDEO C533 nsp nsp CERAMIC CAP. 0.022UF 50V Z HCBS1H223ZFT
VIDEO C534 nsp nsp CERAMIC CAP. 0.022UF 50V Z HCBS1H223ZFT
VIDEO C535 nsp nsp CERAMIC CAP. 0.022UF 50V Z HCBS1H223ZFT
VIDEO C536 nsp 00MOA10701620 ELECT CAP. 100UF 16V ZF CCEA1CH101T
VIDEO C537 nsp 00MOA10701620 ELECT CAP. 100UF 16V ZF CCEA1CH101T
VIDEO C538 nsp 00MOA10701620 ELECT CAP. 100UF 16V ZF CCEA1CH101T
VIDEO C539 nsp 00MOA10701620 ELECT CAP. 100UF 16V ZF CCEA1CH101T
VIDEO C540 nsp 00MOA10701620 ELECT CAP. 100UF 16V ZF CCEA1CH101T
VIDEO C541 nsp 00MOA10701620 ELECT CAP. 100UF 16V ZF CCEA1CH101T
VIDEO C542 nsp 00MOA10701620 ELECT CAP. 100UF 16V ZF CCEA1CH101T
