Marantz SR4500 - Page 54

68
NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI)
PART NAME DESCRIPTION
POS.NO.
VIDEO J593 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
VIDEO J594 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
VIDEO J596 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
VIDEO J605 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
VIDEO J607 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
VIDEO J608 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
VIDEO J615 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
VIDEO J616 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
VIDEO J623 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
VIDEO J624 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
VIDEO J625 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
VIDEO J641 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
VIDEO JK51 90M-YT002950R 90M-YT002950R TERMINAL CJJ4N043Z
VIDEO JK52 90M-YT002950R 90M-YT002950R TERMINAL CJJ4N043Z
VIDEO JK53 90M-YT002940R 90M-YT002940R TERMINAL CJJ4S010Z
VIDEO JK54 90M-YT003250R 90M-YT003250R TERMINAL S-VIDEO (2P/H) CJJ9N001Z
VIDEO JK55 90M-YT003250R 90M-YT003250R TERMINAL S-VIDEO (2P/H) CJJ9N001Z
VIDEO JK56 90M-YT003950R 90M-YT003950R TERMINAL CJJ4N029Z
VIDEO L501 /A1B nsp 90M-FF300220R L.C. FLITTER 5N3-101 CLZ9Z043Z
VIDEO L501 /A1S nsp 90M-FF300220R L.C. FLITTER 5N3-101 CLZ9Z043Z
VIDEO L501 /F1N nsp 90M-FF300210R L.C. FLITTER 5N3-100 CLZ9Z042Z
VIDEO L501 /K1G nsp 90M-FF300220R L.C. FLITTER 5N3-101 CLZ9Z043Z
VIDEO L501 /L1G nsp 90M-FF300210R L.C. FLITTER 5N3-100 CLZ9Z042Z
VIDEO L501 /N1B 90M-FF300220R 90M-FF300220R L.C. FLITTER 5N3-101 CLZ9Z043Z
VIDEO L501 /N1G 90M-FF300220R 90M-FF300220R L.C. FLITTER 5N3-101 CLZ9Z043Z
VIDEO L501 /N1S 90M-FF300220R 90M-FF300220R L.C. FLITTER 5N3-101 CLZ9Z043Z
VIDEO L501 /U1B nsp 90M-FF300210R L.C. FLITTER 5N3-100 CLZ9Z042Z
VIDEO L501 /U1S nsp 90M-FF300210R L.C. FLITTER 5N3-100 CLZ9Z042Z
VIDEO Q505 00MHT30001000 00MHT30001000 TRANSISTOR KTC3199 HVTKTC3199YT
VIDEO Q506 00MHT30001000 00MHT30001000 TRANSISTOR KTC3199 HVTKTC3199YT
VIDEO Q507 00MHT30001000 00MHT30001000 TRANSISTOR KTC3199 HVTKTC3199YT
VIDEO Q508 90M-HT100420R 90M-HT100420R TRANSISTOR A733 HVTKSA733CYT
VIDEO Q509 90M-BA001450R 90M-BA001450R TRANSISTOR KRA107M HVTKRA107MT
VIDEO Q510 90M-HT600010R 90M-HT600010R TRANSISTOR TKTA1266YT HVTKTA1266YT
VIDEO Q512 90M-HT800050R 90M-HT800050R TRANSISTOR KTC3198YT HVTKTC3198YT
VIDEO Q513 90M-HT600010R 90M-HT600010R TRANSISTOR TKTA1266YT HVTKTA1266YT
VIDEO Q514 90M-HT600010R 90M-HT600010R TRANSISTOR TKTA1266YT HVTKTA1266YT
VIDEO Q515 90M-HT800050R 90M-HT800050R TRANSISTOR KTC3198YT HVTKTC3198YT
VIDEO Q516 90M-HT600010R 90M-HT600010R TRANSISTOR TKTA1266YT HVTKTA1266YT
VIDEO Q517 90M-BA001450R 90M-BA001450R TRANSISTOR KRA107M HVTKRA107MT
VIDEO Q518 00MHT30001000 00MHT30001000 TRANSISTOR KTC3199 HVTKTC3199YT
VIDEO R501 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
VIDEO R502 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
VIDEO R503 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
VIDEO R504 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
VIDEO R505 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
VIDEO R506 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
VIDEO R507 nsp nsp RESISTOR 68 OHM 1/5W J CRD20TJ680T
VIDEO R508 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
VIDEO R509 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
VIDEO R510 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
VIDEO R511 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
VIDEO R512 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
VIDEO R513 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
VIDEO R514 nsp nsp RESISTOR 68 OHM 1/5W J CRD20TJ680T
VIDEO R515 nsp nsp RESISTOR 68 OHM 1/5W J CRD20TJ680T
VIDEO R516 nsp nsp RESISTOR 1 OHM 1/5W J CRD20TJ1R0T
VIDEO R517 nsp nsp RESISTOR 1 OHM 1/5W J CRD20TJ1R0T
VIDEO R518 nsp nsp RESISTOR 1 OHM 1/5W J CRD20TJ1R0T
VIDEO R519 nsp nsp RESISTOR 1.8 OHM 1/5W J CRD20TJ1R8T
VIDEO R520 nsp nsp RESISTOR 1.8 OHM 1/4W J CRD25TJ1R8T
VIDEO R521 nsp nsp RESISTOR 1.8 OHM 1/5W J CRD20TJ1R8T
VIDEO R522 nsp nsp RESISTOR 10 OHM 1/5W J CRD20TJ100T
