NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI)
PART NAME DESCRIPTION
POS.NO.
VIDEO R523 nsp nsp RESISTOR 10 OHM 1/5W J CRD20TJ100T
VIDEO R524 nsp nsp RESISTOR 68 OHM 1/5W J CRD20TJ680T
VIDEO R525 nsp nsp RESISTOR 33K OHM 1/5W J CRD20TJ333T
VIDEO R526 nsp nsp RESISTOR 12K OHM 1/5W J CRD20TJ123T
VIDEO R527 nsp nsp RESISTOR 1K OHM 1/5W J CRD20TJ102T
VIDEO R528 nsp nsp RESISTOR 8.2K OHM 1/5W J CRD20TJ822T
VIDEO R529 nsp nsp RESISTOR 8.2K OHM 1/5W J CRD20TJ822T
VIDEO R530 nsp nsp RESISTOR 8.2K OHM 1/5W J CRD20TJ822T
VIDEO R531 nsp nsp RESISTOR 220 OHM 1/5W J CRD20TJ221T
VIDEO R532 nsp nsp RESISTOR 220 OHM 1/5W J CRD20TJ221T
VIDEO R533 nsp nsp RESISTOR 220 OHM 1/5W J CRD20TJ221T
VIDEO R534 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
VIDEO R535 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
VIDEO R536 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
VIDEO R537 nsp nsp RESISTOR 12K OHM 1/5W J CRD20TJ123T
VIDEO R538 nsp nsp RESISTOR 1.2K OHM 1/5W J CRD20TJ122T
VIDEO R539 nsp nsp RESISTOR 1.2K OHM 1/5W J CRD20TJ122T
VIDEO R540 nsp nsp RESISTOR 6.2K OHM 1/5W J CRD20TJ622T
VIDEO R541 nsp nsp RESISTOR 220 OHM 1/5W J CRD20TJ221T
VIDEO R542 nsp nsp RESISTOR 300 OHM 1/5W J CRD20TJ301T
VIDEO R543 nsp nsp RESISTOR 47K OHM 1/5W J CRD20TJ473T
VIDEO R544 nsp nsp RESISTOR 200 OHM 1/5 W CRD20TJ201T
VIDEO R545 nsp nsp RESISTOR 8.2K OHM 1/5W J CRD20TJ822T
VIDEO R546 nsp nsp RESISTOR 1K OHM 1/5W J CRD20TJ102T
VIDEO R547 nsp nsp RESISTOR 1K OHM 1/5W J CRD20TJ102T
VIDEO R548 nsp nsp RESISTOR 1K OHM 1/5W J CRD20TJ102T
VIDEO R549 nsp nsp RESISTOR 1K OHM 1/5W J CRD20TJ102T
VIDEO R550 nsp nsp RESISTOR 8.2K OHM 1/5W J CRD20TJ822T
VIDEO R551 nsp nsp RESISTOR 39 OHM 1/5W J CRD20TJ390T
VIDEO R552 nsp nsp RESISTOR 180 OHM 1/5W J CRD20TJ181T
VIDEO R553 nsp nsp RESISTOR 330 OHM 1/5W J CRD20TJ331T
VIDEO R554 nsp nsp RESISTOR 1.2K OHM 1/5W J CRD20TJ122T
VIDEO R555 nsp nsp RESISTOR 1.2K OHM 1/5W J CRD20TJ122T
VIDEO R556 nsp nsp RESISTOR 15K OHM 1/5W J CRD20TJ153T
VIDEO R561 nsp nsp RESISTOR 8.2 OHM 2W J CRG2ANJ8R2H
VIDEO R562 nsp nsp RESISTOR 8.2K OHM 1/5W J CRD20TJ822T
VIDEO R563 nsp nsp RESISTOR 100 OHM 1/4W CRD25TJ101T
VIDEO R564 nsp nsp RESISTOR 47K OHM 1/5W J CRD20TJ473T
VIDEO R565 nsp nsp RESISTOR 47 OHM 1/5W J CRD20TJ470T
VIDEO R567 nsp nsp RESISTOR 10K OHM 1/5W J CRD20TJ103T
VIDEO R568 nsp nsp RESISTOR 15 OHM 2W J CRG2ANJ150H
VIDEO R569 nsp nsp RESISTOR 33K OHM 1/5W J CRD20TJ333T
VIDEO R570 nsp nsp RESISTOR 22K OHM 1/5W J CRD20TJ223T
INPUT & DSP PCB (CUP11694Z)
INPUT BN10 nsp nsp CONNECTIVE CORD CWB2B904200EN
INPUT BN24 nsp nsp CONNECTIVE CORD CWZSR4500BN24
INPUT C100 nsp 00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
INPUT C104 nsp 00MDK96104300 CERAMIC CAP. 0.1uF HCUS1H104ZF
INPUT C105 nsp 00MDK96104300 CERAMIC CAP. 0.1uF HCUS1H104ZF
INPUT C106 nsp 00MDK96104300 CERAMIC CAP. 0.1uF HCUS1H104ZF
INPUT C107 nsp 00MDK96104300 CERAMIC CAP. 0.1uF HCUS1H104ZF
INPUT C108 nsp 00MOA10800620 ELECT CAP. 1000UF 6.3V CCEA0JH102T
INPUT C109 nsp 00MOA22605020 ELECT CAP. 22UF/25V CCEA1EH220T
INPUT C110 nsp 00MDK96104300 CERAMIC CAP. 0.1uF HCUS1H104ZF
INPUT C111 nsp 00MDK96104300 CERAMIC CAP. 0.1uF HCUS1H104ZF
INPUT C112 nsp 00MOA22605020 ELECT CAP. 22UF/25V CCEA1EH220T
INPUT C115 nsp 00MOA10701020 ELECT CAP. 100UF 10V CCEA1AH101T
INPUT C116 nsp 00MDK96104300 CERAMIC CAP. 0.1uF HCUS1H104ZF
INPUT C117 nsp 00MOA10701020 ELECT CAP. 100UF 10V CCEA1AH101T
INPUT C118 nsp 00MDK96104300 CERAMIC CAP. 0.1uF HCUS1H104ZF
INPUT C120 nsp 00MDK96104300 CERAMIC CAP. 0.1uF HCUS1H104ZF
INPUT C121 nsp 00MDK96104300 CERAMIC CAP. 0.1uF HCUS1H104ZF
INPUT C122 nsp 00MOA22605020 ELECT CAP. 22UF/25V CCEA1EH220T
