Marantz SR5009/U1B - Page 167

FRONT
4
REF No. Part No. Part Name Remarks Q'ty New Ver
C4452,4453 00D2544573981 C,ELECT GE 85C 10UF-M/50V,5*11-5RESMS SY D040100087070S 2
C4454 nsp C,CERAMIC CHIP HIK X7R)01UF-K/50V-1608REEL D011104577160S 1
C4455,4456 nsp C,CERAMIC CHIP TC COG330PF-J/50V-1608REEL D010331167160S 2
C4457,4458 nsp C,CERAMIC CHIP HIK X7R)1000PF-K/50V-1608REEL D011102777160S 2
C4460,4461 nsp C,CERAMIC CHIP HIK X7R001UF-K/50V-1608REEL D011103777160S 2
C4462 nsp C,CERAMIC CHIP HIK X7R)01UF-K/50V-1608REEL D011104577160S 1
C4463 nsp C,ELECT GE 85C 220UF-M/63V,8*5-5RE SRE SY D040221081070S 1
C4464 nsp C,CERAMIC CHIP HIK X7R)01UF-K/50V-1608REEL D011104577160S 1
C4465,4466 nsp C,CERAMIC CHIP TC COG470PF-J/50V-1608REEL D010471167160S 2
C4467 nsp C,CERAMIC CHIP TC COG100PF-J/50V-1608REEL D010101167160S 1
C4469 00D9630293602 C,ELECT GE 85C 1UF-M/50V,5*11-5RESMS SY (Pb Free) D040010087150S 1
C4472,4473 nsp C,FILM POLYESTER ST-001UF-J/100V-5RE PEFAM103J100 PEF TYPE D02010306C060S 2
C4474,4475 00D9630293602 C,ELECT GE 85C 1UF-M/50V,5*11-5RESMS SY (Pb Free) D040010087150S 2
C4476 nsp C,FILM POLYESTER ST-01UF-J/100V-5RE PEFAM104J100 PEF TYPE D02010406C060S 1
C4477 nsp C,FILM POLYESTER ST-0047UF-J/100V-5RE D02047306C060S 1
C4478,4479 nsp C,CERAMIC CHIP HIK X7R)01UF-K/50V-1608REEL D011104577160S 2
C4480 nsp C,CERAMIC CHIP HIK Y5V0047UF-Z/50V-1608REEL D011473597160S 1
OTHER PARTS GROUP
CLAMP401-403 nsp CLAMP HMX9800(ON)(HAITAI) (W=26,L=50)/WIRE(SOLDER) 4330000120000S 3
CLAMP406 nsp CLAMP HMX9800(ON)(HAITAI) (W=26,L=50)/WIRE(SOLDER) 4330000120000S 1
CN4400 nsp CNFPC 10MM 10-11S-40PW 40P AN DIP TOP CONTACT L130100114050S 1
CN4401 nsp CNWAFER 20MM TUC-P05X-B1 BD-TO-BD 5P HOUSING ST (35237-05) L101100030510S 1
CN4402 nsp CN,WIRE 2MM 330MM/5P CKM2002HV-05=20010HS-05 RD2725#24/28 SHLD L002331050210S 1
CP4400 nsp CNWAFER 25MM YMAW025-07R DIP RA L102025070010S 1
CP4401 nsp CNWAFER 20MM TUC-P05P-B1 BD-TO-BD 5P WAFER ST (35336-05) L101100040510S 1
BD4400 nsp COIL,BEAD CB03YTYN121-1608REEL D340160891210S 1
BD4401-4407 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 7
BD4408 nsp COIL,BEAD CB05YTYH221-2012REEL D340201292210S 1
BD4409,4410 nsp R,CHIP THICK 0-J,1/16W-1608REEL
C20000006M160S 2
BKT4001 nsp BRACKET SR5006U1BSPTH t05(CMD1A792) A4/USB 4010215216000S 1
BKT4401 nsp BRACKET AVR3300(E3)(DENON) SPTE 08t/SCREW 4010210196000S 1
! F4400 963652500020S FUSE CHIP 6125FF500-R 500mA FAST-ACTING SUBMINIATURE FUSE G657612505030S 1
FLT4400 172010008005S DISPLAY,FLT GP1261AI 556*25 66T GREEN/SR5006 K530126100010S 1
G4401 nsp RING,TER WIRE 160MM/1P 61640-BS=CKM9919T BK1617#22 8410161010120S 1
JACK4400 963643101150S JACK,D35 JALCO(YKB21-5442V) G401KB215442VS 1
JACK4401 963643101160S TER,RCA 3PIN RCA-328H-1-03(BK,BK,BK) G606328H0300YS 1
JK4400 963643101840S CN,PLUG CONTACT USB A TYPE FEMALE DIP4P BK R/A USB-101 G480040001010S 1
JK4401 963643101120S JACK,D65 PHONE (YUQIU) D65 9P SILVER PJ-612A-9 G402PJ612A09YS 1
LED4406,4407 963263101010S LED,ROUND BL-BUF4V2-HS-AV-FP35-TBF195C RED LED K500032001240S 2
*
LED4408 963263100510S LED,ROUND WEJ3290W-R2H0-BA 3PI RED/YELLOW GREEN BI-COLOR K500032451010S 1
RMC4400 963262012130S MODULE,REMOCON R34ES9A 36KHZ IR REMOCON MODULE P=254MM E940349003610S 1
SW4400-4409 00D9630095305 SW,TACT SKHV10910D01 KB581/LG 160G G180040500010S 10
VEC4400 963667012360S SW,ENCODER EC16B24T01D4ZZZ 24PLUSE 360' L=25MM G121162400060S 1
VEC4401 963667100170D SW,ENCODER EC16B12SAAD4ZZZ G121161200070S 1
★
nsp HOLDER ASSY SR6007U1B(MARANTZ) SPTH t05(CMD1A793) A4/FLT 4328211106000 1
★
nsp HOLDER SR5006U1B(MARANTZ) SPTH t05(CMD1A793) A4/FLT 4320211106000S 1
★
nsp TAPE () NITTO #500,10MM*50M DOUBLE A710000520000S 26
