Marantz SR5009/U1B - Page 168

VIDEO
5
VIDEO PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed b
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
BK : Black model SG : Silver gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D4210-4212 00D2760401905 D,SWITCHING 1SS133-DO34-AXIAL LRC K000013300040S 3
D5617 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
IC5001 963235100700S IC,MONITOR SW NJM2595M-TE1 DMP16 5-INPUT 3-OUTPUT VIDEO SWITCH J171259500010S 1
IC5002 963235100630S IC,MONITOR SW NJM2586AVC3 VIDEO SWITCH SSOP20-C3 J171258600020S 1
Q4200,4201 943214500030S SEMI,CHIP TR/NPN 2SC INC2001AC1 02W/SC-59 ISAHAYA J522020011210S 2
Q4204 943215500020S SEMI,CHIP TR/PNP 2SA RT1P141C 02W/SC-59 ISAHAYA J520101411210S 1
Q4205 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 02W/SC-59 ISAHAYA J522101411210S 1
Q4206,4207 943215500020S SEMI,CHIP TR/PNP 2SA RT1P141C 02W/SC-59 ISAHAYA J520101411210S 2
Q4208 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 02W/SC-59 ISAHAYA J522101411210S 1
Q4209-4211 943215500020S SEMI,CHIP TR/PNP 2SA RT1P141C 02W/SC-59 ISAHAYA J520101411210S 3
Q4213 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 02W/SC-59 ISAHAYA J522101411210S 1
Q4215 943215500020S SEMI,CHIP TR/PNP 2SA RT1P141C 02W/SC-59 ISAHAYA J520101411210S 1
Q4219 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 02W/SC-59 ISAHAYA J522101411210S 1
Q5625,5626 943215500020S SEMI,CHIP TR/PNP 2SA RT1P141C 02W/SC-59 ISAHAYA J520101411210S 2
Q5628 943214500020S SEMI,CHIP TR/NPN 2SC 2SC3052 015W/SC-59 REEL ISAHAYA J522305200050S 1
Q5629 943216500020S SEMI,CHIP TR/NPN 2SC RT1N141C 02W/SC-59 ISAHAYA J522101411210S 1
Q5630 943215500020S SEMI,CHIP TR/PNP 2SA RT1P141C 02W/SC-59 ISAHAYA J520101411210S 1
ZD4200 963202500290D D,ZENER ZJ36B-05W/5MA-52MM SEMTECH K06003R644522S 1
RESISTOR GROUP
R4200,4201 nsp R,CHIP THICK 220-J,1/16W-1608REEL C20002216M160S 2
R4202,4203 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 2
R4212,4213 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 2
R4222 nsp R,CHIP THICK 470-J,1/16W-1608REEL C20004716M160S 1
R4223,4224 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 2
R4225 nsp R,CHIP THICK 470-J,1/16W-1608REEL C20004716M160S 1
R4238,4239 nsp
R,CHIP THICK 470-J,1/16W-1608REEL C20004716M160S 2
R4240 nsp R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160S 1
R4241 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 1
R4242,4243 nsp R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160S 2
R4258 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R4291 nsp R,CHIP THICK 820-J,1/16W-1608REEL C20008216M160S 1
R4295,4296 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 2
R4297,4298 nsp R,CARBON FILM 1K-J,1/5W-52RE-AX C00001026P520S 2
R4299 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 1
R4300 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R4302-4304 nsp R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160S 3
R5002 nsp R,CHIP THICK 82-J,1/16W-1608REEL C20008206M160S 1
R5003 nsp R,CHIP THICK 18K-J,1/16W-1608REEL C20001826M160S 1
R5007,5008 nsp R,CHIP THICK 75-J,1/16W-1608REEL C20007506M160S 2
R5009 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R5011 nsp R,CHIP THICK 75-J,1/16W-1608REEL C20007506M160S 1
R5013,5014 nsp R,CHIP THICK 75-J,1/16W-1608REEL C20007506M160S 2
R5015,5016 nsp R,CHIP THICK 150-J,1/16W-1608REEL C20001516M160S 2
R5017,5018 nsp R,CHIP THICK 160-J,1/16W-1608REEL C20001616M160S 2
R5019,5020 nsp R,CHIP THICK 150-J,1/16W-1608REEL C20001516M160S 2
R5021,5022 nsp R,CHIP THICK 160-J,1/16W-1608REEL C20001616M160S 2
R5023,5024 nsp R,CHIP THICK 150-J,1/16W-1608REEL C20001516M160S 2
R5025,5026 nsp R,CHIP THICK 160-J,1/16W-1608REEL C20001616M160S 2
R5033-5035 nsp R,CHIP THICK 75-J,1/16W-1608REEL C20007506M160S 3
R5036 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R5037-5039 nsp R,CHIP THICK 75-J,1/16W-1608REEL C20007506M160S 3
R5718 nsp R,CARBON FILM 100-J,1/5W-52RE-AX C00001016P520S 1
R5719
nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R5720 nsp R,CHIP THICK 33K-J,1/16W-1608REEL C20003336M160S 1
R5736 nsp R,CHIP THICK 47K-J,1/16W-1608REEL C20004736M160S 1
R5737 nsp R,CHIP THICK 18K-J,1/16W-1608REEL C20001836M160S 1
R5740 nsp R,CHIP THICK 47-J,1/16W-1608REEL C20004706M160S 1
CAPACIITORS GROUP
C4200,4201 nsp C,CERAMIC CHIP TC COG330PF-J/50V-1608REEL D010331167160S 2
C4202,4203 00D9630224503 C,ELECT GE 85C 22UF-M/50V,5*11-5RESMS SY D040220087060S 2
C4207 nsp C,CERAMIC CHIP TC X7R)001UF-K/50V-1608REEL D010103777160S 1
C4220 00D9630244606 C,ELECT GE 85C 01UF-M/50V,5*11-5RESMS SY (Pb Free) D040R10087080S 1
C4221,4222 00D9630224503 C,ELECT GE 85C 22UF-M/50V,5*11-5RESMS SY D040220087060S 2
C4247 00D2544573981 C,ELECT GE 85C 10UF-M/50V,5*11-5RESMS SY D040100087070S 1
C4248-4250 00D9630244606 C,ELECT GE 85C 01UF-M/50V,5*11-5RESMS SY (Pb Free) D040R10087080S 3
C5008-5010 nsp C,CERAMIC CHIP TC COG68PF-J/50V-1608REEL D010680167160S 3
C5011 00D9630293709 C,ELECT GE 85C 100UF-M/10V,5*11-5RESMS SY D040101082070S 1
C5012 nsp C,CERAMIC CHIP TC COG68PF-J/50V-1608REEL D010680167160S 1
C5013,5014 nsp C,CERAMIC CHIP HIK X7R)01UF-K/50V-1608REEL D011104577160S 2
C5015,5016 nsp C,CERAMIC CHIP TC COG68PF-J/50V-1608REEL D010680167160S 2
C5017,5018 00D9630293602 C,ELECT GE 85C 1UF-M/50V,5*11-5RESMS SY (Pb Free) D040010087150S 2
C5019,5020 nsp C,CERAMIC CHIP HIK X7R)01UF-K/50V-1608REEL D011104577160S 2
C5021 00D9630293602 C,ELECT GE 85C 1UF-M/50V,5*11-5RESMS SY (Pb Free) D040010087150S 1
C5022 00D9630293709 C,ELECT GE 85C 100UF-M/10V,5*11-5RESMS SY D040101082070S 1
C5023-5025 00D9630293602 C,ELECT GE 85C 1UF-M/50V,5*11-5RESMS SY (Pb Free) D040010087150S 3
C5026-5028 00D2544573981 C,ELECT GE 85C 10UF-M/50V,5*11-5RESMS SY D040100087070S 3
C5029 00D2544574922 C,ELECT GE 85C 100UF-M/50V,8*115-5RESMS SY D040101087060S 1
C5030 nsp C,CERAMIC CHIP HIK X7R)01UF-K/50V-1608REEL D011104577160S 1
C5031 00D2544574922 C,ELECT GE 85C 100UF-M/50V,8*115-5RESMS SY D040101087060S 1
C5032 nsp C,CERAMIC CHIP HIK X7R)01UF-K/50V-1608REEL D011104577160S
1
C5048 963134502400S C,FILM POLYESTER MI-0.1UF-J/50V-5RE D020104167050S 1
C5051 963134502400S C,FILM POLYESTER MI-0.1UF-J/50V-5RE D020104167050S 1
C5663 nsp C,CERAMIC CHIP HIK X7R)47UF-K/63V-1608REEL D011475571160S 1
C5678,5679 nsp C,CERAMIC CHIP HIK X7R)01UF-K/50V-1608REEL D011104577160S 2
OTHER PARTS GROUP
CLAMP300-302 nsp CLAMP HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 3
CN4002 nsp CN,WAFER 1.25B-2-15Y 15P BtoB SOCKET(FEMALE) P=1.25MM L109125421510S 1
*
CN4003 nsp CN,WAFER 1.25B-2-21Y 21P BtoB SOCKET(FEMALE) P=1.25MM L109125422110S 1
*
CN5000 nsp CN,WAFER 125B-2-11Y 11P BtoB SOCKET(FEMALE) P=125MM L109125421110S 1
*
CN5001 nsp CN,WAFER 125B-2-13Y 13P BtoB SOCKET(FEMALE) P=125MM L109125421310S 1
*
CN5003 nsp CN,WAFER 125B-2-17Y 17P BtoB SOCKET(FEMALE) P=125MM L109125421710S 1
*
CN5004 nsp CN,WAFER 125B-2-7Y 7P BtoB SOCKET(FEMALE) P=125MM L109125420710S 1
*
CP3401 nsp CN,WAFER 1.25B-2-11A 11P BtoB HEADER(MALE) P=1.25MM L109125321110S 1
*
CP3403 nsp CN,WAFER 1.25B-2-21A 21P BtoB HEADER(MALE) P=1.25MM L109125322110S 1
*
