9897
IC98
IC97 IC96 IC95 IC92 IC91
鉛フリー半田
半田付けには、鉛フリー半田
(Sn-Ag-Cu)
を使用してください。
Lead-free Solder
When soldering, use the Lead-free Solder (Sn-Ag-Cu).
DOWNLOADER CONNECTOR A PWB DOWNLOADER CONNECTOR B PWB
BRIDGE DIODE 2 A PWB
BRIDGE DIODE 2 B PWB
REGULATOR 1 A PWB
REGULATOR 1 B PWB
COMPONENT OUT 2 A PWB
COMPONENT OUT 2 B PWB
BRIDGE DIODE 1 A PWB
BRIDGE DIODE 1 B PWB
