Marantz SR6003 - Microprocessor and IC Data

106
13. MICROPROCESSOR AND IC DATA
IC01 : R5F2122AASNFP [SR6003 : USB]
Pin
No
Port Name I/O Use Name
PortSetup
Note
Act. Init
1 P33/SSI I/O I NO USE - H Pull up to +3.3V
2 P34/SDA/SCS I/O SDA SDA - H SDA Reserved
3 MODE I I MODE L H L: Bootmode/H: Normal Operation
4 P43/XCIN I/O O NO USE - L Open
5 P44/XCOUT I/O O NC - L Open
6 RESET I I RESET L H Reset Input
7 P47/XOUT (I/)O O XOUT - - X'tal 20MHz Output
8 VSS/AVSS - - GND - - GND
9 P46/XIN Ｉ(/O) I XIN - - X'tal 20MHz Input
10 VCC/AVCC I I +3.3V - - +3.3V
11 P54/TRCIOD I/O O NO USE - L Open
12 P53/TRCIOC I/O O NO USE - L Open
13 P52/TRCIOB I/O O NO USE - L Open
14 P51/TRCIOA/TRCTRG I/O O NO USE - L Open
15 P50/TRCCLK I/O O NO USE - L Open
16 P27/TRDIOD1
I/O O NO USE - L Open
17 P26/TRDIOC1 I/O O NO USE - L Open
18 P25/TRDIOB1 I/O O NO USE - L Open
19 P24/TRDIOA1 I/O O NO USE - L Open
20 P23/TRDIOD0 I/O O NO USE - L Open
21 P22/TRDIOC0 I/O O NO USE - L Open
22 P21/TRDIOB0 I/O O NO USE - L Open
23 P20/TRDIOA0/TRDCLK I/O O NO USE - L Open
24 P17/TRAIO/INT1 I/O O NO USE - L Open
25 P16/CLK0 I/O O NO USE - L Open
26 P15/RXD0/(TRAIO)/(INT1) I/O I RXD0 - H UART Control Input
27 P14/TXD0 I/O O TXD0 - H UART Control Output
28 P86 I/O O NO USE - L Open
29 P85/TRFO12 I/O O NO USE - L Open
30 P84/TRFO11 I/O O NO USE - L Open
31 P83/TRFO10/TRFI I/O O NO USE - L Open
32 P82/TRFO02 I/O O NO USE - L Open
33 P81/TRFO01 I/O O NO USE - L Open
34 P80/TRFO00 I/O O DAC_RST L H Reset Input
35 P60/TRE0 I/O I IPOD_ERR L H iPod_Error
36 P45/INT0 I/O O NO USE - L Open
37 P66/INT2/TXD1 I/O TXD TXD1 - H UART Program Output
38 P67/INT3/RXD1 I/O RXD RXD1 - H UART Program Input
39 P65/(CLK1)/CLK2 I/O O SCK - H SCK to USB Controller
40 P64/RXD2 I/O RXD SO - H SO from USB Controller
41 P63/TXD2 I/O TXD SI - H SI to USB Controller
42 P31/TRBO I/O O RTS - H RTS to USB Controller
43 P30/TRAO I/O O USB_RST L H Reset Input
44 P36/(INT1) I/O O STBY L H Standby Output
45 P32/(INT2) I/O I CTS - H CTS from USB Controller
46 P13/KI3/AN11 I/O KIN DDI ↑ L Operation Pulse Input
47 P12/KI2/AN10 I/O O MSB_LSB - L LSB_MSB First Select Output
48 P11/KI1/AN9 I/O O NO USE - L Open
49 P10/KI0/AN8 I/O ANA NO USE - - Reserved
50 P00/AN7 I/O ANA HW_REV - - Hardware Revision Detect
51 P01/AN6 I/O O NO USE - L Open
52 P02/AN5 I/O O NO USE - L Open
53 P03/AN4 I/O O NO USE - L Open
54 P04/AN3 I/O O NO USE - L Open
55 P62 I/O O NO USE - L Open
56 P61 I/O O NO USE - L Open
