111
Pin
No.
Port Name Vcc
I/O
Volt
I/O Use STBY Name
PortSetup
Note
Act. Init
37
P7-0/TA0out/TxD2/
SDA2/SRxD2/INPC1-
6/
OUTC1-6/OUTC2-0/
ISTxD2/IEout/RTP0-2
P1 +5V I/O SIO I V_SDA - H
I2C Data for Video Devices (ADV7401/
ADV7342)
38
P6-7/TxD1/SDA1/
SRxD1
P1 +5V I/O SC O TXD - H RS-232C Output
39 Vcc1 P1Vcc +5V I YES I VCC1 - - +5V'
40
P6-6/RxD1/SCL1/
STxD1
P1 +5V I/O SI I RXD - H RS-232C Input
41 Vss Vss I - I VSS - - GND
42 P6-5/CLK1 P1 +5V I/O O O(Lo) S2P_STB - H Port Expander Strobe
43
P6-4/_CTS1/_RTS1/_
SS1/OUTC2-1/ISCLK2
P1 +5V I/O I I SPKC_DET H L Speaker-C Switch
44
P6-3/TxD0/SDA0/
SRxD0/IrDAout
P1 +5V I/O SIO I HDMI_SDA - H I2C Data for HDMI CPU
45
P6-2/RxD0/SCL0/
STxD0/IrDAin
P1 +5V I/O SC I HDMI_SCL - H I2C Clock for HDMI CPU
46 P6-1/CLK0/RTP0-1 P1 +5V I/O O I RS232_SW RS232C_SW1 CONTROL
47
P6-0/_CTS0/_RTS0/_
SS0/RTP0-0
P1
+5V I/O O I RS232_SW2 L - RS232C_SW2 CONTROL
48 P13-7/OUTC2-7 P2 +3.3V I/O O I HDMI_RST H H HDMI CPU Reset
49
P13-6/OUTC2-1/
ISCLK2
P2 +3.3V I/O SC O(Lo) SPIO_CLK - L Serial Clock Output for DSP (DA788)
50
P13-5/OUTC2-2/
ISRxD2/IEin
P2 +3.3V I/O SI I SPIO_SOMI - L Serial Data Input from DSP (DA788)
51
P13-4/OUTC2-0/
ISTxD2/IEout
P2 +3.3V I/O SO I SPIO_SIMO - H Serial Data Output for DSP (DA788)
52 P5-7/_RDY P2 +3.3V I/O I I IPSD_WAIT - - Wait from Video Scaler
53 P5-6/ALE P2 +3.3V I/O O I NO USE L - No Use
54 P5-5/_HOLD P2 +3.3V I/O I I _BOOT - - L : Boot Mode/ H: Normal Operation
55 P5-4/_HLDA/ALE P2 +3.3V I/O O I _HLDA/ALE L No Use
56 P13-3/OUTC2-3 P2 +3.3V I/O O I S_MUTE H H SL/SR Mute
57 Vss Vss I - I VSS - - GND
58 P13-2/OUTC2-6 P2 +3.3V I/O O I F_MUTE H H L/R Mute
59 Vcc2
P2Vcc +3.3V I YES I VCC2 - - +3.3V
60 P13-1/OUTC2-5 P2 +3.3V I/O O I M_MUTE H H ZONE A Mute
61 P13-0/OUTC2-4 P2 +3.3V I/O O I C_MUTE H H Center Mute
62
P5-3/CLKout/BCLK/
ALE
P2 +3.3V I/O O I IPSD_CLK H Video Scaler Clock
63 P5-2/_RD P2 +3.3V I/O O I IPSD_RD_ L - Video Scaler Read
64 P5-1/_WRH/_BHE P2 +3.3V I/O O I BHE - - No Use
65 P5-0/_WRL/_WR P2 +3.3V I/O O I IPSD_WR_ L - Video Scaler Write
66 P12-7 P2 +3.3V I/O I I MIC_DET L H Microphone Jack Switch Input
67 P12-6 P2 +3.3V I/O O I SW_MUTE H L SW Mute
68 P12-5 P2 +3.3V I/O O I TV_AUTO H L TV Signal Detect
69 P4-7/_CS0/_A23 P2 +3.3V I/O O I IPSD_CS0_ - - Video Scaler CS0
70 P4-6/_CS1/A22 P2 +3.3V I/O O I _CS1 - - No Use
71 P4-5/_CS2/A21 P2 +3.3V
I/O O I _CS2 - - No Use
72 P4-4/_CS3/A20 P2 +3.3V I/O O I _CS3 - - No Use
73 P4-3/A19 P2 +3.3V I/O O I SB_MUTE H H SBL/SBR Mute
74 Vcc2 P2Vcc +3.3V I YES I VCC2 - - +3.3V
75 P4-2/A18 P2 +3.3V I/O O I _CEFL L L Front FL Driver Chip Select
76 Vss Vss I - I VSS - - GND
77 P4-1/A17 P2 +3.3V I/O I I SEL- L H Front Select Knob Encoder -
78 P4-0/A16 P2 +3.3V I/O I I SEL+ L H Front Select Knob Encoder +
79 P3-7/A15(/D15) P2 +3.3V I/O I/O I A15/D15 - No Use
80 P3-6/A14(/D14) P2 +3.3V I/O I/O I A14/D14 - No Use
IC11 : M3087BFLK [SR5003 : MAIN] / M3087BFL [SR6003 : MAIN]
