113
IC11 : M3087BFLK [SR5003 : MAIN] / M3087BFL [SR6003 : MAIN]
Pin
No.
Port Name Vcc
I/O
Volt
I/O Use STBY Name
PortSetup
Note
Act. Init
128
P15-2/AN15-2/
ISRxD0/RxD5
P1 +5V I/O Rx I SIRIUS RX SIRIUS UART Input (U1B only)
129
P15-1/AN15-1/
ISCLK0/CLK5
P1 +5V I/O O I HDMI_MD L H HDMI CPU H: Boot/L: Normal Operation
130 Vss Vss I - I VSS - - GND
131
P15-0/AN15-0/
ISRxD0/TxD5
P1 +5V I/O Tx I SIRIUS TX SIRIUS UART Output (U1B only)
132 Vcc1 P1Vcc +5V I YES I VCC1 - - +5V
133
P10-7/AN7/_KI3/
RTP3-3
P1 +5V I/O AD AD MODE2 - - Model Name Setting
134
P10-6/AN6/_KI2/
RTP3-2
P1 +5V I/O AD AD MODE1 - - Destination Setting
135
P10-5/AN5/_KI1/
RTP3-1
P1 +5V I/O O I
STANDBY_
LED
L - Standby LED
136
P10-4/AN4/_KI0/
RTP3-0
P1 +5V I/O O I
STANDBY_
RL
L L Standby Relay Control
137 P10-3/AN3/RTP1-3 P1 +5V I/O AD AD _5V_DOWN - - +5VD Supply Voltage Detect
138 P10-2/AN2/RTP1-2 P1 +5V I/O AD AD
KEY2 - - Front Key 2 Input
139 P10-1/AN1/RTP1-1 P1 +5V I/O AD AD KEY1 - - Front Key 1Input
140 Avss AVss I - I AVSS - - GND
141 P10-0/AN0/RTP1-0 P1 +5V I/O AD AD KEY0 - - Front Key 0 Input
142 Vref Vref +5V I YES I VCC - - +5V
143 Avcc AvccVcc +5V I YES I AVCC - - +5V
144
P9-7/_ADTRG/RxD4/
SCL4/STxD4
P1 +5V I/O O I DMP_RX - L USB UART Input (SR6003 only)
