Marantz SR7009/U1B - Page 126

+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
-2-0.5=-2.5dB
200mVrms
+30dB
SP OUT
4.48Vrms/8Ω
+29dB
-2+6.5=+4.5dB
MAX. SIGNAL LEVEL
DOLBY LIMIT LEVEL (ALLch-3dBFS)
-20dBFS(DIG.IN)
-2.6dB
2.83Vrms=0dBFS
-10dBFS
-20dBFS
-30dBFS
-40dBFS
PCM1690 Differential Out
-2.6dB
PRE OUT
159mVrms
-26.5dBFS(A/D IN)
R2A15218FP/R2A15220FP MAX. OUTPUT 3.8Vrms
MASTER VOL 00dB時のGAIN設定
･DOLBY DIGITAL IN -2dB +0.5dB =-2.5dB
･ANALOG IN -2dB +6.5dB =+4.5dB
① ② ③
①:Basic OFFSET of VOL=0dB (indication valude)
②:OFFSET of A/D input
③:System compensation of Digital Input
DD INPUT:-20dBFS SURR. 1kHz
ANA INPUT:200mVrms L+R 1kHz
(MODE:MULTI CH STEREO)
SR7009
LEVEL DIAGRAM
SURROUND ch
＋
SPEAKER
R2A15220FP
PRE OUT
R2A15218FP
GAIN
ADJ.
＋
DSP
PCM1690
D/A
－
－
＋
PLD
MUTE
HDAM
EXT IN
126
