Marantz SR7009/U1B - Smps Pcb; Trans Power

(4) Removetheconnectorwire.Removethescrews.
7. SMPS PCB
Proceeding : TOP COVER
→
BACK CHASSIS
→
DIGITAL PCB
→
SMPS PCB
See"EXPLODEDVIEW"forinstructionsonhowtoremoveeachPCBofthe"SMPS PCB".
8. TRANS POWER
Proceeding : TOP COVER
→
BACK CHASSIS
→
DIGITAL PCB
→
TRANS POWER
See"EXPLODEDVIEW"forinstructionsonhowtoremoveeachPCBofthe"TRANS POWER".
CN971
CUT
