Marantz SR7009/U1B - Digital Pcb

3. DIGITAL PCB
Proceeding : TOP COVER → BACK CHASSIS → DIGITAL PCB
(1) Removethescrews.RemovetheNutandWasherformtheantennaconnector.
(2) Cutthewireclamp,thenremovetheconnectorwiresandFFC.
(3) Removetheconnector.
CY920 Model
CX870 Model
FFC
CN903
FFC
CN914
CN916
CON1
CON2
CN704
CON1
CON2
CN321
CX870 ONLY
STYLE PIN
STYLE PIN
CUT
CUT
ANT.
CUT
STYLE PIN
Front side
BN24A BN25A BN21ABN26A
BN23A
BN27A
d
16
