Marantz SR7009/U1B - Page 220

INPUT
13
REF No. Part No. Part Name Remarks Q'ty New Ver
C4627,4628 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H331JAS 2
C4633,4634 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H331JAS 2
C4637,4638 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H331JAS 2
C4643,4644 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H331JAS 2
C4647,4648 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H331JAS 2
C4661,4662 nsp CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG GeneralCapacitors-C0G N/K CCUS1H101JAS 2 2
C4663,4664 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 2
C4665,4666 nsp CAP,CHIP(1608,50V/220pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H221JAS 2
C4675,4676 nsp CAP,ELECT(10V/220uF) CCEA1AH221T 2
C4677,4678 nsp CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H101JAS 2
C4679,4680 nsp CAP,MYLAR(50V/0.022uF/J) HCQI1H223JZT 2
C4681,4682 943139001260S CAP,MYLAR(50V/6800pF/J) HCQI1H682JZT 2
C4687-4690 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 4
C4701,4702 00D2544569937 CAP,ELECT(25V/220uF,ELNA/RA3) CCEA1ERA38P221T 2
C4703,4704 nsp CAP,ELECT(16V/100uF) CCEA1CH101T 2
C4705 00D2544569937 CAP,ELECT(25V/220uF,ELNA/RA3) CCEA1ERA38P221T 1
C4706-4708 nsp CAP,ELECT(16V/100uF) CCEA1CH101T 3
C4727,4728 nsp CAP,ELECT(50V/100uF),ELNA/RA3 CCEA1HRA3101T 2
C4729,4730 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T 2
C4761-4763 00D2544574919 CAP,ELECT(50V/47uF),ELNA/RA3 CCEA1HRA3470T 3
C4764-4773 00D9430175001 CAP,ELECT(25V/47uF) CCEA1EH470T 10
C4774,4775 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 2
C4781-4784 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 4
C4801,4802 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 2
C4803-4806 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H103KCS 4
C4811,4812 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 2
C4819,4820 nsp CAP,CHIP(1608,50V/68pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H680JAS 2
C4823,4824 nsp
CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H101JAS 2
C4825-4828 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 4
C4831,4832 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 2
C4837,4838 nsp CAP,CHIP(1608,50V/3300pF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H332KCS 2 *
C4839,4840 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 2
C4841,4842 nsp CAP,ELECT(50V/4.7uF) CCEA1HH4R7T 2
C4843 943134501580S CAP,ELECT(25V/33uF) CCEA1EH330T 1
C4844 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C4845 943134501580S CAP,ELECT(25V/33uF) CCEA1EH330T 1
C4851,4852 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 2
C4853-4856 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H103KCS 4
C4861,4862 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 2
C4869,4870 nsp CAP,CHIP(1608,50V/68pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H680JAS 2
C4873,4874 nsp CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H101JAS 2
C4875-4878 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 4
C4881,4882 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 2
C4887,4888 nsp CAP,CHIP(1608,50V/3300pF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H332KCS 2 *
C4889,4890 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 2
C4891,4892 nsp CAP,ELECT(50V/4.7uF) CCEA1HH4R7T 2
C4893 943134501580S CAP,ELECT(25V/33uF) CCEA1EH330T 1
C4894 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C4895 943134501580S CAP,ELECT(25V/33uF) CCEA1EH330T 1
C4901-4908 nsp CAP,ELECT(16V/100uF) CCEA1CH101T 8
C4935,4936 nsp CAP,ELECT(25V/220uF) CCEA1EH221T 2
C8707,8708 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 2
C8709,8710 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H331JAS 2
C8723,8724 nsp CAP,ELECT(50V/22uF) CCEA1HH220T
2
C8727,8728 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 2
C8729,8730 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H331JAS 2
C8739 nsp CAP,ELECT(50V/0.1uF) CCEA1HH0R1T 1
C8740 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H103KCS 1
C8743,8744 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 2
C8747,8748 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 2
C8749,8750 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H331JAS 2
C8759 nsp CAP,ELECT(50V/0.1uF) CCEA1HH0R1T 1
C8767,8768 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 2
C8769,8770 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H331JAS 2
C8780 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H103KCS 1
C8787,8788 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 2
C8789,8790 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H331JAS 2
C8800 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H103KCS 1
C8803 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 1
C8807 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 1
C8809 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H331JAS 1
C8819 nsp CAP,ELECT(50V/0.1uF) CCEA1HH0R1T 1
C8820 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H103KCS 1
C8827,8828 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 2
C8829,8830 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H331JAS 2
C8840 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H103KCS 1
C8849 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C8869 nsp CAP,ELECT(50V/0.1uF) CCEA1HH0R1T 1
C8913,8914 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 2
C8917,8918 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 2
C8919,8920 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG GeneralCapacitors-C0G
CCUS1H331JAS 2
C8929 nsp CAP,ELECT(50V/0.47uF) CCEA1HHR47T 1
C8963,8964 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 2
C8967,8968 nsp CAP,ELECT(50V/22uF) CCEA1HH220T 2
C8969,8970 nsp CAP,CHIP(1608,50V/330pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H331JAS 2
C8979 nsp CAP,ELECT(50V/0.47uF) CCEA1HHR47T 1
C8980 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H103KCS 1
C8991,8992 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUS1H104KCS 2
OTHER PARTS GROUP
CN101 nsp WAFER,FFC,SMD(23P-1mm,STRAIGHT) CJP23GA193ZY 1
CN706 nsp LOCK-WAFER/STRAIGHT/2MMPITCH/3PIN CJP03GI288ZY 1
CN87A nsp PINHEADER(27P,1.25mm,STRAIGHT,B-TO-B) CJP27GI281Z 1
CN87C nsp PINHEADER(27P,1.25mm,STRAIGHT,B-TO-B) CJP27GI281Z 1
CN88A nsp PINHEADER(25P,1.25mm,STRAIGHT,B-TO-B) CJP25GI281Z 1
CN88C nsp PINHEADER(25P,1.25mm,STRAIGHT,B-TO-B) CJP25GI281Z 1
CN89A nsp PINHEADER(21P,1.25mm,STRAIGHT,B-TO-B) CJP21GI281Z 1
CN89C nsp PINHEADER(21P,1.25mm,STRAIGHT,B-TO-B) CJP21GI281Z 1
BK103 nsp EARTH,HDMI CMC2A436 1 *
BK469 nsp EARTH,INPUT CMC1A440 1
BN23C nsp PINSOCKET(21P,1.25mm,ANGLE,B-TO-B) CJP21HJ282Z 1
BN24C nsp PINSOCKET(27P,1.25mm,ANGLE,B-TO-B) CJP27HJ282Z 1
BN26C nsp PINSOCKET(15P,1.25mm,ANGLE,B-TO-B) CJP15HJ282Z 1
BN461
EXPLODED C41
nsp WIREASS'YLocking(YH)(13P,2MM,180MM,#26) WIREASS'Y CWB1B013180HC 1 *
BN462
EXPLODED C40
nsp
WIREASS'YLOCKING(3P,2.0MM,300MM,UL1007#26) WIREASS'YLOCKING(3P,2.0MM,300MM,UL100
CWB1B003300HC 1
