DIGITAL
35
REF No. Part No. Part Name Remarks Q'ty New Ver
C4180 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C4181 nsp CAP,CHIP(1005,25V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1E103KCS 1
C4182 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C4183 nsp CAP,CHIP(1005,25V/0.01uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1E103KCS 1
C4201-4216 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 16
C4219 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG HighCapacitance-X5R CCUS0J475KCS 1
C4220-4223 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 4
C4224 nsp CAP,ALUMINUMELECTROLYTIC(16V/10uF) CCEC1CMVG100T 1
C4301-4303 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 3
C4304 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG HighCapacitance-X7R,X7S CCUS1A105KCS 1
C4305 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C4306 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG HighCapacitance-X7R,X7S CCUS1A105KCS 1
C4307 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C4308 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG HighCapacitance-X7R,X7S CCUS1A105KCS 1
C4309 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C4310 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG HighCapacitance-X7R,X7S CCUS1A105KCS 1
C4311-4335 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 25
C4336 nsp CAP,CHIP(1608,50V/10pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H100JAS 1
C4337 nsp CAP,CHIP(1608,50V/9pF,C0G)_SAMSUNG GeneralCapacitors-C0G CCUS1H090DAS 1
C4338 nsp CAP,CHIP(1005,50V/1000pF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1H102KCS 1
C4339-4346 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 8
C4353-4361 nsp CAP,CHIP(1005,50V/1000pF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1H102KCS 9
C4371-4373 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG HighCapacitance-X7R,X7S CCUS1A105KCS 3
C4381-4384 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG HighCapacitance-X5R CCUS0J475KCS 4
C4396,4397 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG HighCapacitance-X5R CCUS0J475KCS 2
C4404,4405 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG HighCapacitance-X5R CCUS0J475KCS 2
C4411,4412 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG HighCapacitance-X5R CCUS0J475KCS 2
C4417,4418 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG HighCapacitance-X5R CCUS0J475KCS
2
C4420,4421 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG HighCapacitance-X5R CCUS0J475KCS 2
C4423,4424 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG HighCapacitance-X5R CCUS0J475KCS 2
C4425 nsp CAP,SMDELECT(16V/47uF) SMDELECTCAP(16V/47uF) CCEC1CMVG470T 1 *
C4428,4429 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG HighCapacitance-X5R CCUS0J475KCS 2
C5001 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C5002 nsp CAP,CHIP(1005,50V/1000pF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1H102KCS 1
C5011,5012 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG HighCapacitance-X5R CCUS0J475KCS 2
C5013,5014 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 2
C5021,5022 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG HighCapacitance-X5R CCUS0J475KCS 2
C5023,5024 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 2
C5031,5032 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG HighCapacitance-X5R CCUS0J475KCS 2
C5033,5034 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 2
C5041,5042 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG HighCapacitance-X5R CCUS0J475KCS 2
C5043,5044 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 2
C5091 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CY920 Model CCUI1C104KCS 1 3
C5092,5093 nsp CAP,CHIP(1608,10V/1uF,X7R,X7S)_SAMSUNG CY920 Model CCUS1A105KCS 2 3
C5094 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG CY920 Model CCUI1C104KCS 1 3
C5101 nsp CAP,CHIP(1005,16V/0.1uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1C104KCS 1
C5111 nsp CAP,CHIP(1005,25V/0.022uF,X7R)_SAMSUNG GeneralCapacitors-X7R CCUI1E223KCS 1
OTHER PARTS GROUP
CN431 nsp WAFER,FFC,SMD(23P-1mm,STRAIGHT) CJP23GA193ZY 1
CN501,502 nsp WAFER,64pin(2x32x1.27mm)SMDTYPE 1.27Boxheader2*32PSMD CJP64GA312ZP 2
CN69B nsp WAFER,FFC,SMD(40P-1mm,STRAIGHT) CJP40GA193ZY 1
CN321 nsp LOCK-WAFER/STRAIGHT/2MMPITCH/5PIN CY920 Model CJP05GI288ZY 1 3
CN704 nsp WAFER,2mm,SMD,Vertical,07p CJP07GA208ZY 1
CN781 nsp WAFER,SMD(2MMPITCH) CJP06GA208ZY 1
CN903 nsp LOCK-WAFER/STRAIGHT/2.5MMPITCH/5PIN CJP05GI289ZY 1
CN904 nsp WAFER,SMD(2MMPITCH)-4P 2mmPitch4PStraightSMDWafer CJP04GA208ZY 1
BK101-103 nsp BRACKET,PCB CMD1A569-V1 3
BK104,105 nsp BRACKET,NETWORKA CMD1A900 2
BN21A nsp PINSOCKET(19P,1.25mm,ANGLE,B-TO-B) CJP19HJ282Z 1
BN23A,24 nsp PINSOCKET(27P,1.25mm,ANGLE,B-TO-B) CJP27HJ282Z 2
BN25A nsp PINSOCKET(23P,1.25mm,ANGLE,B-TO-B) CJP23HJ282Z 1
BN26A nsp PINSOCKET(09P,1.25mm,ANGLE,B-TO-B) CJP09HJ282Z 1
BN27A nsp PINSOCKET(15P,1.25mm,ANGLE,B-TO-B) CJP15HJ282Z 1
JK201 90M-YT003480R JACK,2P(B/B),GOLD CJJ4N023Z 1
JK202,203 943262100150S MODULE,OPTICAL(RX16MHz) CJSJSR1124 2
JK381-384 943643102920S JACK,HDMI(TYPE-A,SMT-19P,WITHFLANGE) SMT-19PTYPE,WITHFLANGE CJJ9H021Z 4
JK391-394 943643102920S JACK,HDMI(TYPE-A,SMT-19P,WITHFLANGE) SMT-19PTYPE,WITHFLANGE CJJ9H021Z 4
JK431,432 943643102920S JACK,HDMI(TYPE-A,SMT-19P,WITHFLANGE) SMT-19PTYPE,WITHFLANGE CJJ9H021Z 2
JK501 943643102430S JACK,RJ-45W/TRANSFORMER 10/100Base1X1Tab-Down CJJ9L029Z 1
L1001-1007 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 7
L1008 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1009 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
L1010 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1011-1013 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 3
L1014,1015 nsp
FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 2
L1016-1034 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 19
L1111 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1113,1114 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 2
L1121 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1124 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1131 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1134 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1141 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1144 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1151 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1154 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1161 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1164 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1171 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1174 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1181 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1184 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1191 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1194 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1201 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1204 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1211-1213 nsp FERRITECHIPBEAD(2012/220R)
CLZBLM21PG221SN
3
L1214 nsp FERRITECHIPBEAD(2012/120R)
CLZBLM21AG121SN
1
L1215 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1218 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L2201 nsp FERRITECHIPBEAD(2012/220R,CB05YTYH221) CLZ9R018V 1
L3501-3513 nsp FERRITECHIPBEAD(2012/220R)
CLZBLM21PG221SN
13
L3801-3808 nsp FERRITECHIPBEAD(2012/220R)
CLZBLM21PG221SN
8
L3901-3908 nsp FERRITECHIPBEAD(2012/220R)
CLZBLM21PG221SN
8
L3909 943113100000S COMMONMODEFILTER(1210,90ohm) EXC24CH9000U,90OHM,CUTOFFFREQ6GHz CLZ9Z188Z 1
L4001-4008 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 8
