Marantz SR7009/U1B - Page 99

Device display during rmware update
Display of target device during rmware update.
Target device DPMS Update Display Error code when an error occurs
MainCPU
L1
M a i n * * * m i n
L2
U p d a t i n g * * %
10-16
36-3F
Sub
L1
S u b * * * m i n
L2
U p d a t i n g * * %
50-52
54-58
5A-62
AudioPLD
L1
A P L D * * * m i n
L2
U p d a t i n g * * %
50-52
54-58
5A-62
VIDEOPLD
L1
V P L D * * * m i n
L2
U p d a t i n g * * %
50-52
54-58
5A-62
DSP
L1
D S P 1 * * * m i n
L2
U p d a t i n g * * %
L1
D S P 2 * * * m i n
L1
D S P 3 * * * m i n
L1
D S P 4 * * * m i n
50-52
54-58
5A-62
GUISerialFlash
L1
G U I * * * m i n
L2
U p d a t i n g * * %
50-52
54-58
5A
62
80-86
CX870/CY920second
BootLoad-
er
L1
E t h e r S B L * * * m i n
L2
U p d a t i n g * * %
A0-A4
A6-A7
AE-B5
CX870/CY920
L1
E t h e r I M G * * * m i n
L2
U p d a t i n g * * %
A0-A4
A6-A7
AE-B5
CX870/CY920
IImage(Emer-
gencyMode)
L1
P l e a s e w a i t . . .
L2
U p d a t e r e t r y
–
Checking the Firmware Version After an Update
After updating the rmware, check the version.
See "
1. Version Display Mode
" (21 page).
99
