TS 910 TRANSFER SWITCH
PM140 REV 2 14/01/23 48 Thomson Power Systems
Refer to Section 18.15.1 for the factory default settings of the Utility Return
Delay timer
18.15.9 CURRENT TRANSFORMER SIZE JUMPERS
A TSC 9 PCB mounted jumper is provided to configure the size of current transformers
which are utilized when the kW Load shed option is used with the transfer switch.
When the kW Load shed option is not used, no jumper setting is required. Additional
information on TS 910 kW Load shed optional accessory can be obtained from our
Website (
www.thomsontechnology.com ).
