Markes International Unity 2 - Page 62

QUI-1057
Page 62
Markes International Ltd
T: +44 (0)1443 230935 F: +44 (0)1443 231531 E: enquiries@markes.com
www.markes.com
Disconnect the thermocouple and heater wire
connectors
1. Loosen the 4 screws highlighted
2. Slide the whole assembly back to allow access to
the brass connector and hold in position by
tightening one of the rear screws.
2.
1.
