F1 : M_MENU F2 : A_MARK F3 : EDIT F4 : FILE
F5 : SETUP F6 : TEST F7 : LOAD F8 : COMM
X_HOME X_LIMIT Y_HOME Y_LIMIT
[ TEST MODE]
DATE_SET : Yy Mm Dd TIME_SET : Hh Bb Ss
2006/ 05/ 26 12: 45: 45
SENSOR [OFF] [OFF] [OFF] [OFF]
SOL. VALVE1: [OFF] SOL.VALVE2: [OFF]
SOL. ON : DEL_KEY SOL. OFF :INS_KEY
X POSITION = 20.00mm.
Y POSITION = 20.00mm.
Check the step motor:
At F6 mode, if you press an arrow keyà The pin will go to the right hand side.
Whenever you click the Arrow key, marking pin moves per 10mm.
Also if you press no. “5” on the keyboard, the pin will return to home position.
You can check the condition of the step motor of X/Y –axis here.
It is the problem of the motor if the pin was not moving to the any direction.
please check the motor and driver which Axis has problem
CHECK the Sol. Valve:
Check the condition of sol. Value whether to check the stroke of marking pin. It is the problem if the
marking pin doesn`t come out.
l If you press “DEL” on the keyboard, ”SOL. Valve 1””SOL. VALVE 2”on the controller is ON.
l In order to let it OFF, press “INS” key on the keyboard.
You can adjust the date and the time on the F6 mode..
Adjustment of the data and the time (F6 TEST MODE)
1 5 : 2 2 : 0 2 Adjustment 20 0 6: 0 5: 2 2: Adjustment
Press S Press D
Press (Shift+S) Press (Shift+D)
Press B Press M
Press (Shift+B) Press (Shift+M)
Press H Press Y
Press (Shift+H) Press (Shift+Y)
2 0 0 7
Press Y ( 0~9)
Press Shift + Y
200->201->202->->210
*Can be set up from 2000 to 2199
