F3 Screen: Cylinder marking
**Caution : Unit of numeric data on EDIT is 0.1mm.
**Caution : Can change the mode using [SPACE BAR].
**Caution : Can move the cursor using [ENTER] and moving between each block is using (↑,↓).
.
BLK NO.[000] : Block no.
: Select marking type. Press SPACE BAR to change the Menu
EMT : Empty block (Default value)
LIN : Linear marking.
CIR : Circular marking.
PLT : Logo file marking after loading CAD file.
CYL : Cylinder marking.
2DM : 2D Data matrix marking
X : Center of circle for X axis from Zero point (30mm is X:0300 <Unit : 0.1mm>
Y: Center of circle for Y axis from Zero point (30mm is X:0300 <Unit : 0.1mm>
R: Radius of work-piece ( Radius 30mm is R:0300.)
F1 : M_MENU F2 : A_MARK F3 : EDIT F4 : FILE
F5 : SETUP F6 : TEST F7 : LOAD F8 : COMM
BLK NO. [ 000 ]
CYL X : 0300 Y : 0300 R:150 A:000
FNT : STD1 CH:030 PX:030 L:00000000 I:00
<DATA> PAUSE : N
ABCD
[EDIT MODE]
BLK_COPY : CTRL_C BLK_MOVE : UP/DOWN
CURSOR_MOVE : ENTER SELECT : SPACE_BAR
BLK NO. [ 001 ]
EMT
< NO BLOCK DATA >
