Example of communication mode

F1 : M_MENU F2 : A_MARK F3 : EDIT F4 : FILE

F5 : SETUP F6 : TEST F7 : LOAD F8 : COMM

BLK NO. [ 000 ]

LN X : 0300 Y : 0300 A : 000

FNT : STD1 CH:030 PX:030 L:00000000 I:+1

<DATA> PAUSE : N

JEIL MTECH

[EDIT MODE]

BLK_COPY : CTRL_C BLK_MOVE : UP/DOWN

CURSOR_MOVE : ENTER SELECT : SPACE_BAR

BLK NO. [ 001 ]

EMT

< NO BLOCK DATA >

In case enter the data like above, enter the data like below order.

1. <ESC>@; //Initialization (Memory Clear)

2. <ESC>G1; // Select LINEAR marking

3. <ESC>H0; // Select STD1 Font

4. <ESC>I300; // Input X Axis value

5. <ESC>J300; // Input Y Axis value

6. <ESC>L000; // Angle value

7. <ESC>M030; // Pitch value between the letters

8. <ESC>O030; // Character size value

9. <ESC>UJEIL MTECH; // Input the marking data

10. <ESC>!; // input the start signal

In case make more than 2 block data, please see the following.

1. <ESC>@; 10.<ESC>Z; // Increment of block no.

2. <ESC>G1; 11.<ESC>G1;

3. <ESC>H0; 12.<ESC>H0;

4. <ESC>I300; 13.<ESC>I300;

5. <ESC>J300; 14.<ESC>J400;

6. <ESC>L000; 15.<ESC>L000;

7. <ESC>M030; 16.<ESC>M030;

8. <ESC>O030; 17.<ESC>O030;

9. <ESC>UJEIL MTECH; 18.<ESC>U12345;

19. <ESC>!;

Do not need to input the value which is “0” (Zero).
