F1 : M_MENU F2 : A_MARK F3 : EDIT F4 : FILE
F5 : SETUP F6 : TEST F7 : LOAD F8 : COMM
X_HOME X_LIMIT Y_HOME Y_LIMIT
[ TEST MODE]
DATE_SET : Yy Mm Dd TIME_SET : Hh Bb Ss
2011/ 02/ 14 12: 45: 45
SENSOR [OFF] [OFF] [OFF] [OFF]
SOL. VALVE1: [OFF] SOL.VALVE2: [OFF]
SOL. ON : DEL_KEY SOL. OFF :INS_KEY
X POSITION = 20.00mm.
Y POSITION = 20.00mm.
2. Press the keys which can change the time on the above screen.
3. [Modification of Year] In case modify the year, 2011 will be changed 2021 if press capital letter “Y”
2011 will be changed 2012 if press lower case letter “y”.
4. [Modification of Month] In case modify the month. 02 will be changed 12 if press capital letter”M”.
02 will be changed 03 if press lower case letter “y”.
5. [Modification of Date] In case modify the date, 14 will be changed 24 if press capital letter”D”.
14 will be changed 15 if press lower case letter “d”.
6. [Modification of Hour] In case modify the hour, 12 will be changed 22 if press capital letter”H”
12 will be changed 13 if press lower case letter “h”.
7. [Modification of Minute] ] In case modify the minute, 45 will be changed 55 if press capital letter ”B”
45 will be changed 46 if press lower case letter “b”.
8. [Modification of Second] In case modify the second, 45 will be changed 55 if press capital letter ”S”
12 will be changed 13 if press lower case letter “s”.
9. Press F2 if all setting value is changed for marking.
**In case of communication mode by RS-232, press [F8] Communication mode.
