Disconnect power at the AC branch circuit breaker.
Use the PV input terminal disconnect tool to remove the PV input cables.
Unscrew the AC grid-connected thread and remove the cable.
After unscrewing the grounding screw and removing the grounding cable, you can move the
balcony photovoltaic integrated machine.
A. Removal of balcony photovoltaic integration
Please write down the serial number of your new balcony photovoltaic integrated machine.
Please make sure that the AC branch circuit breaker is turned off, and then install the
replacement parts according to the balcony photovoltaic integrated machine installation steps.
B. Replacement of the balcony PV unit in the monitoring platform
5.4 Equipment Replacement
Danger
Warn
Warn
Warn
Warn
Do not dismantle the balcony photovoltaic integrated machine without authorization! To ensure
safety and insulation performance, users are prohibited from repairing internal parts!
The AC output harness (AC tapping cable on the balcony photovoltaic integrated machine) must
not be replaced. If the wires are damaged, the device should be scrapped.
Unless otherwise specified, the equipment must be disconnected from the grid (disconnect the
socket) and the PV input during maintenance.
Never use rags made of filamentous or corrosive materials to clean the device, as this may
generate static electricity or cause corrosion.
Do not repair the product yourself. When repairing, use only qualified parts.
Each branch line should be equipped with a circuit breaker, but it is not necessary to have a
central protective device.
Tips
