12 MAC 600/E
Personality settings
* Setting may be overridden via DMX. See the protocol for details.
Personality Path Options Effect (Default settings shaded.)
Pan/tilt speed
PTSP
FAST
Optimize movement for speed.*
NORM
Optimize movement for smoothness.*
Pan/tilt swap
PATI/SWAP
ON
Map DMX pan control to tilt channel and vice versa.
OFF
Normal pan and tilt control.
Pan inverse PATI/PINV
ON
Reverse DMX pan control, right
Æ
left.
OFF
Normal pan control, left
Æ
right.
Tilt inverse PATI/TINV
ON
Reverse DMX tilt control, down
Æ
up.
OFF
Normal tilt control, up
Æ
down
Tracking algorithm SPEC/TRAC/MOdE
MOd1
Absolute delta value algorithm (for most controllers)
MOd2
Real delta value algorithm
Tracking samples SPEC/TRAC/CAL
1-10
Tracking samples. Increase if pan/tilt is not smooth.
Effects speed EFSP
FAST
Normal, full speed operation.
SAFE
Reduced speed operation (mainly for early models).
Display on/off SPEC/dISP
ON
Display stays on.
OFF
Display goes out 2 minutes after last key press.
Display intensity SPEC/dINT
10-100
Adjust display intensity.
DMX lamp off SPEC/dLOF
ON
Enable DMX lamp off command.
OFF
Disable DMX lamp off command.*
DMX reset SPEC/dRES
ON
Enable DMX reset command.
OFF
Disable DMX reset command.*
Automatic lamp on SPEC/ALON
ON
Lamp strikes automatically within 90 seconds of power on.
OFF
Strike lamp from controller.
Automatic protocol
detection
SPEC/AUTO
ON
Enable automatic protocol detection.
OFF
Disable automatic protocol detection.
Shortcuts SPEC/SCUT
ON
Effect wheels turn the shortest direction.*
OFF
Effect wheels always turn same direction.*
Automatic shutter SPEC/ASHT
ON
Shutter “helps” dimmer black out.
OFF
Shutter not affected by dimmer commands.
Studio mode MOdE
NORM
Optimize effects for speed.*
STUd
Optimize effects for silence.*
Pan/tilt feedback SPEC/FEbA
ON
Enable pan/tilt position correction system.
OFF
Disable pan/tilt feedback. Setting not saved.
Effects feedback SPEC/EFFb
ON
Enable feedback on effect wheels.
OFF
Disable feedback on effect wheels.
Fan speed SPEC/FAN
REG
Enable automatic fan speed regulation.
FULL
Set fan speed to full.
Electronic ballast
type
SPEC/ETYP
SCHI
Select Schiederwerk ballast (MAC 600 E's after S/N
4020700000)
MITR
Select Mitronic ballast (MAC 600 E’s with date-based S/N or
before S/N 4020700000)
