Martin MAC 600E - DMX Protocol

20 MAC 600/E
appendix a
DMX PROTOCOL
DMX channel Start code = 0
DMX1 DMX2 DMX3 DMX4 Value Percent Function
1
Note:
Lamp Off is allowed with SPEC/dLoF
set to ON, or with SPEC/dLoF set to
OFF and cyan, magenta and yellow
set between 230 and 232.
Reset is allowed with SPEC/dRES
set to ON, or with SPEC/dRES set to
OFF and cyan, magenta and yellow
set between 230 and 232.
0 - 19
20 - 49
50 - 112
113 - 115
116 - 122
123 - 127
128 - 147
148 - 167
168 - 187
188 - 207
208 - 217
218 - 227
228 - 237
238 - 247
248 - 255
0 - 7
8 - 19
20 - 44
44 - 45
45 - 48
48 - 50
50 - 58
58 - 65
66 - 73
74 - 81
82 - 85
85 - 89
89 - 93
93 - 97
97 - 100
Shutter, Strobe, Reset, Lamp On/Off
Shutter closed
Shutter open
Strobe on (fast->slow)
Shutter closed
Shutter open, reduced lamp power (MAC 600 E)
Shutter closed
Random Strobe Fast
Random Strobe Medium
Random Strobe Slow
Shutter closed
Reset Fixture
Shutter closed
Lamp power on
Shutter closed
Lamp power off Note: T ≥ 5 seconds
2
0 - 255 0 - 100
Intensity
0 Æ 100%
3
0-255 0 - 100
Cyan
White Æ Cyan
4
0-255 0 - 100
Magenta
White Æ Magenta
5
0-255 0 - 100
Yellow
White Æ Yellow
6
0 - 40
40 - 80
80 - 120
120 - 160
161 - 165
166 - 170
171 - 175
176 - 180
181 - 185
186 - 214
215 - 243
244 - 247
248 - 251
252 - 255
0 - 16
16 - 31
31 - 47
47 - 63
63 - 65
65 - 67
67 - 69
69 - 71
71 - 73
73 - 84
84 - 95
96 - 97
97 - 98
99 - 100
Color Wheel
Scroll
White Æ Color 1
Color 1 Æ Color 2
Color 2 Æ Color 3
Color 3 Æ Color 4
Fixed Colors
Color 4
Color 3
Color 2
Color 1
White
Continuous Rotation
CW, fast Æ slow
CCW, slow Æ fast
Random CMY Color
Random color, fast
Random color, medium
Random color, slow
70
1 - 255
0
0 - 100
Beam Shaper 1
Open
Beam shaper left Æ right
8
0 - 2
3 - 170
171 - 255
0 - 1
1 - 67
67 - 100
Beam Shaper 2
Open
Beam shaper left Æ right
Frost
9
0 - 255 0 - 100
Pan Coarse (16-bit MSB)
Left Æ right (128 = neutral)
-10-10
0 - 255 0 - 100
Pan Fine (16-bit LSB)
Left Æ right
