30 MAC TW1 user manual
Control menu
Menu Item Options Notes (Default settings in bold print)
–
(16-bit basic)
–
(16-bit extended)
DMX address (new fixtures are supplied with address set to 1)
16-bit basic DMX mode with 2-channel (coarse and fine) control of
pan and tilt
16-bit extended DMX mode with basic mode features plus fine
control of electronic and mechanical dimmers, cyan, magenta,
yellow and zoom
Normal pan and tilt control
Map DMX pan control to tilt channel and vice versa
Normal pan control: left Æ right
Reverse DMX pan control: right Æ left
Normal tilt control: up Æ down
Reverse DMX tilt control, down Æ up
Normal pan/tilt speed
Optimize pan/tilt movement for speed
Normal effects speed
Optimize effects movement for speed
Pan/tilt speed slave: effects speed copies the pan/tilt speed set
via the control menu or via DMX
Display remains on
Display goes into sleep mode 2 minutes after last key press
Display goes into sleep mode 10 minutes after last key press
Display adjusts automatically for ambient light level
–
Adjust display intensity manually
Enable reset via DMX
Disable reset via DMX
Enable reset via DMX when reset command is held for 5 seconds
CMY filters move shortest distance (across open)
CMY filters do not cross open
Linear dimming curve (VRMS: voltage root mean square)
Square-law dimming curve
Normal mode: pan, tilt and effects set to normal speed, fans
obey control menu (
Æ) setting
Studio mode: pan, tilt and effects set to normal speed, fans set to
temperature-regulated (overrides other control menu settings)
‘Silent’ mode: pan, tilt and effects set to slow speed, fans set to off
(overrides other control menu settings)
/ Enable lamp pre-heat (OFF by default)
- 0.0 - 20.0% lamp preheat value (1.0% by default)
/ Enable economy mode: reduced lamp power (OFF by
default)
- 70 - 100% lamp power value (80% by default)
Return all settings (except calibrations) to factory defaults
,,
Load custom configuration
Save current custom configuration
Table 3: Control menu
