Adjustment submenu
The Æ menu is for use by service technicians when performing adjustments.
Item Options Notes
Reset fixture
Cyan effect on switch
Minimum cyan position
Maximum cyan position
–
Cyan rotation clockwise slow - counterclockwise fast
Magenta effect on switch
Minimum magenta position
Maximum magenta position
–
Magenta rotation clockwise slow - counterclockwise fast
Yellow effect on switch
Minimum yellow position
Maximum yellow position
–
Yellow rotation clockwise slow - counterclockwise fast
Shutter adjustment position
Shutter closed
Shutter open
Slow shutter strobe
Medium shutter strobe
Fast shutter strobe
Zoom module positioned on switch
Zoom near position
Zoom far position
Test all effects in effects module: service use only
Pan and tilt neutral positions
Pan neutral, tilt down
Pan neutral, tilt up
Pan left, tilt neutral
Pan right, tilt neutral
Pan left, tilt down
Pan right, tilt up
Table 5: Adjustment submenu
