Maschio TERMINATOR - Assembly Drawing and Components

Code F07011709
g.6
8
1
2
3
4
5
MASCHIO GASPARDO INDIA PVT. LTD.
Plot No. F27, MIDC, Ranjangaon, Village Karegaon, Tal Shirur, Dist. Pune 412220 India
Ph.:+91 2138 621500. Email : info@maschio.in Website : www.maschio.com
PRODUCT
MODEL
TYPE
SERIAL
NUMBER
H.P.
REQ.
YEAR OF MANUFACTURE
F20200163 Made in India
WEIGHT
kg
7
6
9
10
11
USE AND MAINTENANCE
ENGLISH
17
3.2 ASSEMBLY DRAWING (g.6)
1 - Support hook for cardan shaft
2 - 3rd connection, upper point
3 - Three point hitch
4 - Overdrive unit
5 - Identication plate
6 - Side transmission spacer
7 - Side transmission guard
8 - PVC rear protection
9 - 3rd connections, lower points
10- Cardan shaft connection
11 - Cardan shaft protection
