Radical-7 Signal Extraction Pulse CO-Oximeter Service Manual
6-3
Symptom Cause and Corrective Action
Steps
2. Replace Display
• 005
• Dual UART Failed at Power Up
1. Replace Portable System Board
• 006
• Oximeter Board Failure
1. Replace Oximeter Board
• 007
• Oximeter MX Board
Communication Error
1. Verify Oximeter Board (SET)
Software is correct
a. If version is incorrect or not
displayed, return unit to an
authorized service center or use
a field upgrade tool to reload
the oximeter board software.
b. If version is correct, replace
Oximeter Board.
c. Replace Portable System Board
• 008
• Real Time Clock Failure
1. Replace Portable System Board
• 009
• Watchdog Failure
1. Replace Portable System Board
• 010 • Docking Station Watchdog
Failure
1. Replace Docking Station System
Board.
2. Replace Portable System Board
• 200 • Invalid SatShare coefficients
1. Replace Docking Station System
Board.
Symptom Cause and Corrective Action
Steps
• All Flashing LED's
1. Flashing alternates between
all LED's and AC Power
LED.
2. Refer to Radical-7
Operators
Manual for LED status
Parameters.
• Communication error between
Portable and Docking Station
1. Verify software versions of
Portable and Docking Station
System Boards using the Portable
menu
a. If versions are incorrect or not
displayed, reload System
Application Software for that
device utilizing procedures
outlined in the Software
