Masimo Rad-G Quick Start Guide

Troubleshooting Guide
Message on
Device
Attach cable
Conrm cable fully
inserted into device
Disconnect and
reconnect cable
Replace cable if not
resolved
Close cable latch
No Cable No Sensor
Attach sensor
Conrm sensor fully
inserted into device
Conrm red light
illuminated on sensor
Replace sensor if not
resolved
Sensor Lifespan - Two (2) weeks with continuous use
Cable Lifespan - Two (2)
years with continuous use
Masimo® Rad-G® Quick Start Guide
©2024 Ontario Ventilator Equipment Pool. All rights reserved.
Date of Issue: 2022-10-19. Rev. 2024-02-13.

Masimo Rad-G Specifications

General

Type	Handheld Pulse Oximeter
Ingress Protection	IP22
Operating Temperature	5°C to 40°C
Storage Temperature	-20°C to 60°C
SpO2 Range	0% to 100%
Pulse Rate Range	25 – 240 bpm
Battery Type	Rechargeable Lithium-ion
Connectivity	Bluetooth
Perfusion Index Range	0.02% to 20%
PVI Range	0% - 100%
Humidity	10% to 95% (non-condensing)
