Masimo Root Manual

Root with Pathway Operation
www.masimo.com 13 Masimo
Additional Settings
From the Additional Settings screen, change any of the following options:
Option Description Factory Default
Settings
User Configurable
Settings
SmartTone Allows the audible pulse to continue to
beep when the pleth graph shows signs
of motion.
Off On or Off
SpO2 Pathway Alarms
The SpO2 Pathway Alarms allow the user to optionally adjust alarm limits during the first 10
minutes when used in Pathway mode. After 10 minutes, the alarm limits revert to the ones
set as part of the SpO2 Parameter Settings.
From the SpO
2
Pathway Alarms settings screen, change any of the following options:
Options Description Factory Default
Settings
User Configurable
Settings
High
Limit
High Limit is the upper threshold that
triggers an alarm.
99 2 to 99 in steps of
1, or Off
Low Limit Low Limit is the lower threshold that
triggers an alarm.
88 1 to 98 in steps of 1
Silence
Duration
Sets the amount of time that the alarm is
silenced.
2 minutes 30 seconds, 1 or 2
minutes
Rapid
Desat
Sets the Rapid Desat limit threshold to
the selected amount below the Low Alarm
Limit. When SpO
2
value falls below rapid
desat limit the audio and visual alarm are
immediately triggered without respect to
the alarm delay.
-10 Off, -5, or -10

Masimo Root Specifications

General

Category	Medical Equipment
Display	10.1 inch touchscreen
Connectivity	WiFi, Bluetooth
Power Supply	AC power
Dimensions	26.8 cm x 22.4 cm x 5.1 cm
Ports	USB, Ethernet
Supported Parameters	SpO2, Pulse Rate
Compatibility	Masimo sensors
Model	Root
