Masimo Root Manual

Root with Pathway Operation
www.masimo.com 12 Masimo
Pathway Settings
Pathway settings include the following:
Parameter Settings*, **
See Parameter Settings on page 12.
Additional Settings
See Additional Settings on page 13.
SpO2 Pathway Alarms**
See SpO2 Pathway Alarms on page 13.
SpO2 Target Range
See SpO2 Target Range on page 14.
PR Threshold
See PR Threshold on page 15.
* Only displays when Radical-7 is docked to Root.
** The SpO2 Pathway Alarms control the alarm limits during the first 10 minutes of Pathway
operation. After 10 minutes of Pathway operation, the SpO2 Parameter Settings control the
alarm limits.
Parameter Settings
Parameter Settings display only when Radical-7 is docked to Root.
Note: The Neonatal profile is selected by default for all Radical-7 parameter settings during
Pathway operation.
For information about configuring the Parameter Settings related to Pathway, refer to Chapter
3: Operation of the Operator's Manual, Radical-7 Pulse CO-Oximeter.

Masimo Root Specifications

General

Category	Medical Equipment
Display	10.1 inch touchscreen
Connectivity	WiFi, Bluetooth
Power Supply	AC power
Dimensions	26.8 cm x 22.4 cm x 5.1 cm
Ports	USB, Ethernet
Supported Parameters	SpO2, Pulse Rate
Compatibility	Masimo sensors
Model	Root
