Mastech MS2203 User Manual

( Figure 14. The Third Phase Power Measurements )
5. After above every phase measurement, turn the selector to ∑W,
then the display shows total Active Power value and Power Factor
value of the three-phase load (Figure 15). After display for three
seconds, the display switches to show total Apparent Power value
and total Reactive Power value automatically(Figure 16). The total
Apparent Power value is in the primary display and the total
Reactive Power value is in the secondary display. The display
switches automatically every three seconds until you turn the
meter to other function.
